Bose Professional 791354-1410 FreeSpace 2 120V AC,4 ohms
ZA 2120-LZA|1B-791354141
Bose Professional 791354-1410 FreeSpace 2 120V AC,4 ohms
ZA 2120-LZA|1B-791354141
Bose Professional
Bose Professional 791354-1410 FreeSpace 2 120V AC,4 ohms
ZA 2120-LZA | 1B-791354141
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The Bose® FreeSpace® ZA 2120-LZA zone amplifier is designed to provide basic amplification and sound system expansion when using front-end Bose products such as FreeSpace® integrated zone amplifiers and ControlSpace® engineered sound processors. With the inclusion of AmpLink, up to 8 digital audio channels can be sent to the amp from a Bose DSP via a shielded CAT 5 cable.
Key Features
- Reliable 2 x 120 W Class-D amplification optimized for low-impedance applications.
- AmpLink transports up to 8 uncompressed, near zero latency, digital audio channels between Bose DSPs and the ZA 2120-LZA via shielded CAT 5 cable. The amp also supports a THRU path for daisy-chaining digital audio to other Bose AmpLink products at a distance of up to 10 m between products.
- Remote option for volume control eliminates the need for bulky, inefficient, and
- sound-altering in-line volume controls.
- Expansion-ready connectivity with FreeSpace® IZA amplifiers and ControlSpace® engineered sound processors when additional sources and loudspeaker processing is required.
- Intuitive feature setup enables the amplifier to be configured without a PC for input, output and automatic standby options.
- Auto-Standby feature allows the amplifier to consume less power when not in use.
- Remote muting allows the amplifier to be muted via a centralized control system.
Main Features
- Reliable 2 x 120 W Class-D Alification optimized for low-impedance applications
- ALink transports up to 8 uncompressed, near zero latency, digital audio channels between Bose DSPs and the ZA 2120-LZA via shielded CAT 5 cable. The A also supports a THRU path for daisy-chaining digital audio to other Bose ALink products at a distance of up to 10 m between products
- Remote option for volume control eliminates the need for bulky, inefficient, and sound-altering in-line volume controls
- Expansion-ready connectivity with FreeSpace IZA amplifiers and ControlSpace engineered sound processors when additional sources and loudspeaker processing is required
- Intuitive feature setup enables the amplifier to be configured without a PC for input, output and automatic standby options
- Auto-Standby feature allows the amplifier to consume less power when not in use
- Remote muting allows the amplifier to be muted via a centralized control system
General Information
Name: Bose Professional 791354-1410 FreeSpace 2 120V AC,4 ohms
Category: Bose Professional, Pro AV, Commercial Audio, Pro Amplifiers
UPC Code: 017817772723
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number 1B-791354141 Brand Name Bose Professional Manufacturer Bose Corporation Manufacturer Part Number 791354-1410 Product Line FreeSpace Product Model ZA 2120-LZA Product Name FreeSpace ZA 2120-LZA Zone Amplifier Product Series FS Product Type Amplifier Weight 9lb
Audio Channels 2 Classification D Impedance 4 Ohms
Maximum Frequency Response 20 kHz Minimum Frequency Response 20Hz RMS Output Power 240W Total Harmonic Distortion (THD) 0.5%
Operating Power Consumption 300W
Ethernet Yes
Depth 12.8" Height 1.7" Width 19"
Input Voltage 120V AC
Limited Warranty 5-Year
Features Auto-Standby feature allows the amplifier to consume less power when not in use., Expansion-ready connectivity with FreeSpace IZA amplifiers and ControlSpace engineered sound processors when additional sources and loudspeaker processing is required., Intuitive feature setup enables the amplifier to be configured without a PC for input, output and automatic standby options., Reliable 2 x 120 W Class-D amplification optimized for low-impedance applications., Remote muting allows the amplifier to be muted via a centralized control system., Remote option for volume control eliminates the need for bulky, inefficient, and sound-altering in-line volume controls. Indoor/Outdoor Indoor, Outdoor
