Product Overview
A high-performance, 3-phase, modular, scalable, power protection solution with industry-leading efficiency, capacity, and performance for medium to large data centers and mission critical environments.
Main Features
- High-performance 3-phase power protection
- Modular and scalable design
- Industry-leading efficiency
- Ideal for medium to large data centers
- Suitable for mission critical environments
General Information
Name: APC SY400K500DL-PD Symmetra PX 400kW Scalable to 500kW, 400kW, 500kW
Category: APC by Schneider Electric, Batteries & Power Supplies, Power Management, UPS
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 2G-0K500DLPP Brand Name APC by Schneider Electric Manufacturer Schneider Electric SA Manufacturer Part Number SY400K500DL-PD Packaged Quantity 1 Pack Product Line Symmetra PX Product Name Symmetra PX 400kW Modular UPS Product Type Double Conversion Online UPS Weight 16391.37 lb
Output Voltage 400V AC, 415V AC, 480V AC Phase Three Phase Receptacle Detail 1 x Hard Wire 4-wire (3PH + G), 1 x Hard Wire 5-wire (3PH + N + G) Receptacle Type Hard Wire 4-wire (3PH + G), Hard Wire 5-wire (3PH + N + G) Transfer Time 2 ms
Battery Characteristics Valve-regulated Battery Chemistry Lead Acid Battery Life 8 Year Battery Recharge Time 3.5-Hour
Maximum Operating Elevation 3333 ft Maximum Operating Temperature 104°F (40°C) Maximum Storage Elevation 50000 ft Thermal Dissipation 14.51 kW
EPO Port Yes
Network Management Modbus, Network Management Card 2
Application/Usage Data Center, Mission Critical Equipment, Server Color Black Depth 42.1" Form Factor Modular Height 78.4" Width 17.1 ft
Input Frequency 40 Hz|70 Hz Input Voltage 400V AC, 415V AC, 480V AC Output Frequency 50 Hz|60 Hz Waveform Type Sine Wave
Limited Warranty 1-Year
Environmental Certification UL Environmentally Friendly Yes
