APC SY500K500DR-PD Symmetra PX 500kW Scalable with Rig
SY500K500DR-PD|2G-0K500DRPD
APC SY500K500DR-PD Symmetra PX 500kW Scalable with Rig
SY500K500DR-PD|2G-0K500DRPD
APC by Schneider Electric
APC SY500K500DR-PD Symmetra PX 500kW Scalable with Rig
SY500K500DR-PD | 2G-0K500DRPD
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Scalable, high-efficiency 3-phase UPS with integrated maintenance bypass & sub-feed distribution. This system scales as your data center grows up to 500kW/500kVA. Up to four systems can be connected in parallel to provide 2MW of power protection. Suitable for medium & large data center applications.
Main Features
- Scalable 3-phase UPS up to 500kW/500kVA
- Integrated maintenance bypass and sub-feed distribution
- Connect up to four systems for 2MW power protection
- High-efficiency suitable for medium and large data centers
- Ideal for growing data center applications
General Information
Name: APC SY500K500DR-PD Symmetra PX 500kW Scalable with Rig
Category: APC by Schneider Electric, Batteries & Power Supplies, Power Management, UPS
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 2G-0K500DRPD Brand Name APC by Schneider Electric Manufacturer Schneider Electric SA Manufacturer Part Number SY500K500DR-PD Product Line Symmetra Product Name Symmetra PX 500kW Scalable to 500kW Tower UPS Product Series PX Product Type Double Conversion Online UPS Weight 4437 lb
Backup/Run Time (Full Load) 6.50 Minute Backup/Run Time (Half Load) 21 Minute Output Voltage 480V AC Receptacle Detail 1 x Hard Wire 4-wire, 1 x Hard Wire 5-wire Receptacle Type Hard Wire 4-wire, Hard Wire 5-wire Transfer Time 2 ms
Battery Characteristics Valve Regulated Lead Acid (VRLA) Battery Chemistry Lead Acid Battery Recharge Time 8-Hour
Energy Star Yes
Maximum Operating Elevation 3333' Maximum Operating Temperature 104?F Maximum Storage Elevation 5000' Thermal Dissipation 18138W
Network Management SNMP Manageable
Application/Usage Data Center, Mission Critical Equipment Depth 42" Height 78.4" Width 86.6"
Input Frequency 70 Hz Input Voltage 220V AC Output Frequency 60 Hz Plug/Connector Type Hard Wire 4-wire, Hard Wire 5-wire
Limited Warranty 1-Year
Environmental Certification Green Premium, UL Environmentally Friendly Yes Package Contents - Symmetra PX 500kW Scalable to 500kW Tower UPS
- 192 x Battery Module
- Installation guide
- User Manual
- Web/SNMP Management Card
