APC AP8887 Rack PDU 2G, Metered, 17.3KW, 240V
AP8887 | 2G-AP8887
Please sign in to view pricing and availability and to add to cart.
Product Overview
APC Metered Rack Power Distribution Units (PDUs) provide active metering to enable energy optimization and circuit protection. User-defined alarm thresholds mitigate risk with real-time local and remote alerts to warn of potential circuit overloads. Metered Rack PDUs provide power utilization data to allow Data Center Managers to make informed decisions on load balancing and right sizing IT environments to lower total cost of ownership. Metered Rack PDUs include real power monitoring, a temperature/humidity sensor port, locking IEC receptacles, and ultra low profile circuit breakers. Users can access and configure Metered Rack PDUs through secure Web, SNMP, or Telnet Interfaces which are complimented by APC Centralized Management platforms using InfraStruxure Central, Operations, Capacity, and Energy Efficiency.
Main Features
- Monitor load level efficiently with PDU meter
- IEC 60320 C13 receptacle type to ensure maximum productivity with added feasibility
- IEC 60309 30A 3P+N+E plug/connector type for reliable, productive connectivity and optimal power output
- 400 V input voltage for optimal performance with maximum usability
- 240 V AC output voltage for better reliance and maximum usability
- 240 V AC output voltage for optimal performance with maximum feasibility
General Information
Specifications
ADI Part Number 2G-AP8887 Brand Name APC by Schneider Electric Manufacturer Schneider Electric SA Manufacturer Part Number AP8887 Packaged Quantity 1 Product Line Metered Rack Product Name Rack PDU 2G, Metered, ZeroU, 17.3kW, 240V, (30) C13 & (12) C19 Product Type PDU Sector Data Comm & Networking Weight 21.16lb
Output Voltage 240V PDU Type Metered Receptacle Detail 12 x IEC 60320 C19, 30 x IEC 60320 C13 Receptacle Type IEC 60320 C13, IEC 60320 C19
Color Black Depth 2.01" Form Factor Tower Height 72.01" Rack Height 0U Width 2.20"
Input Voltage 400V Plug/Connector Type IEC 60309 30A 3P+N+E
Mount Type Rack Mount Protection Type Overload Protection
Limited Warranty 2-Year
Country of Origin PH Environmental Certification cUL Listed, UL Listed, VCCI Class A Environmentally Friendly Yes Package Contents - Rack PDU 2G, Metered, ZeroU, 17.3kW, 240V, (30) C13 & (12) C19
- Installation guide
- Rack mounting brackets
- Safety guide
- Serial configuration cable
