APC AR106VI NETSHELTER WX 6U Low-Profile Wallmount Enclosure
APC AR106VI NETSHELTER WX 6U Low-Profile Wallmount Enclosure
APC AR106VI NETSHELTER WX 6U Low-Profile Wallmount Enclosure
AR106VI | 2G-AR106VI
Please sign in to view pricing and availability and to add to cart.
Product Overview
NetShelter WX 6U Low-Profile Wall Mount Enclosure 230V Fans
APC By Schneider Electric 6U Wall Mount is an innovative new way to deploy server and networking equipment at the Edge. The unique low-profile design enables large depth devices to be wall mounted in a compact and less intrusive form factor than traditional wall mount cabinets. It can ship pre-integrated with APC Smart UPS battery backup, NetBotz Physical and Environmental Security, and EcoStruxure IT, our cloud-based remote monitoring platform to stay connected at the Edge!
Air filtration and ventilation
Replaceable MERV 5/G3 dust filter and integrated fans allow equipment to be placed in dusty and light industrial environments
Enhanced physical security
Protect against physical and environmental threats with camera monitoring, keylock doors, intrusion detection, temperature/humidity monitoring, leak detection, and more
High weight load capacity
Supports equipment up to 250lbs (113kg) of total load
Integrator Ready
Shock Packaging allows all equipment to be pre-integrated into the enclosure before it arrives on-site, speeding up and standardizing deployments
Low-Profile Design
Extends less than 13" (330mm) off of the wall while supporting equipment up to 30" (762mm) deep, including 1 and 2U hyperconverged servers, UPS, and network switches
Wall mount or floor standing
The detachable wall bracket and optional casters allow the enclosure to be mounted on the wall or floor, depending on the site requirements
Main Features
- Rack Cabinet allows quick and easy retrieval of your items with better organizing and feasible mounting
- Comes in black color for a sophisticated and dazzling loo
- Wall Mountable form factor allows hassle-free and easy usage with increased efficiency
- Networking application, usage for easy accessibility with items, valuables, equipment organizational, storage, placement convenience
- Side-to-side Airflow feature for better items, valuables, equipment organizational, storage, placement reliance?
General Information
Specifications
ADI Part Number 2G-AR106VI Brand Name APC by Schneider Electric Manufacturer Schneider Electric SA Manufacturer Part Number AR106VI Product Line NetShelter WX Product Model AR106VI Product Name NetShelter WX 6U Low-Profile Wall Mount Enclosure 230V Fans Product Type Rack Cabinet Weight 80.01lb
Application/Usage Airflow System, Converged Infrastructure, Networking, Server, Storage Color Black Depth 38.1" Form Factor Wall Mount Height 25.5" Width 13.9"
Mount Type Wall Mount
Limited Warranty 5-Year
Assembly Required No Certifications & Standards UL 2416 Compatibility - 2/4U Servers
- 1U Servers
- Side-to-Side Airflow
Environmental Certification UL Features Side-to-side Airflow
