Product Overview
A highly compact, energy efficient, 65kAIC rated 3-phase UPS with parallel capability for data centers, facility and industrial applications.
Main Features
- Compact and energy-efficient design
- 65kAIC rated for high performance
- 3-phase UPS for balanced power distribution
- Parallel capability for scalability
- Ideal for data centers and industrial use
General Information
Name: APC GVMPB180KG65S UPS, 180 KVA, 480V, Parallel
Category: APC by Schneider Electric, Batteries & Power Supplies, Power Management, UPS
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 2G-B180G65S Brand Name APC by Schneider Electric Manufacturer Part Number GVMPB180KG65S Packaged Quantity 1-Pack Product Line Galaxy VM Product Name Galaxy VM 180 kVA UPS Parallel Product Type UPS Weight 1497.93 lb
Output Voltage 480V AC Phase Three Phase Receptacle Detail 1 x Hard Wire 4-wire (3PH + G), 1 x Hard Wire 5-wire (3PH + N + G) Receptacle Type Hard Wire 4-wire (3PH + G), Hard Wire 5-wire (3PH + N + G)
Energy Star Yes
Maximum Operating Elevation 3333' Maximum Operating Temperature 104?F Maximum Storage Elevation 49212' Thermal Dissipation 6201.3W
EPO Port Yes
Application/Usage Data Center, Industrial Color White Depth 33.6" Height 77.6" Width 39.4"
Input Frequency 40 Hz|70 Hz Input Voltage 480V Output Frequency 50 Hz|60 Hz Waveform Type Sine Wave
Environmental Certification FCC, UL Environmentally Friendly Yes
