Image of 60-PA2120
Yamaha

Yamaha PA2120 Power Amplifier with 1-Stereo / 2-Mono Line Inputs, 2x120W

PA2120|60-PA2120
Yamaha

Yamaha PA2120 Power Amplifier with 1-Stereo / 2-Mono Line Inputs, 2x120W

PA2120|60-PA2120

Sign In for Dealer Pricing

Become an ADI Customer
Image of 60-PA2120
Yamaha

Yamaha PA2120 Power Amplifier with 1-Stereo / 2-Mono Line Inputs, 2x120W

PA2120 | 60-PA2120

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

With quick, easy setup and intuitive operation, the compact MA and PA series power amplifiers make it easier than ever to bring your commercial space to life. The MA2030a and PA2030a are ideal audio solutions for retail stores, eateries, classrooms or public facilities like hospitals. The MA2120 and PA2120 meet the demands of a wide range of applications requiring higher power as well as more flexible DSP functionality and zone control. All models combine approachable, unobtrusive design with efficient, flexible performance. The MA2030a and MA2120 offer mixing capability with source EQ (Bass/Treble) control, as well as some of the same state-of-the-art DSP technol-ogies that are acclaimed features of professional Yamaha audio gear. Whether providing background music for a café or restaurant or powering a conference room or other application requiring microphone input, the MA/PA series amplifiers are simple yet powerful tools that can help establish an ideal commercial sound environment. Lo-Z/Hi-Z switchable Class-D amplifier (Lo-Z: 120W x2 @4?, 100W x2ch @3?/8?,?Hi-Z: 120W x2ch or 200W x1ch, 70V/100V) equipped with 1 stereo/2 mono line inputs; can be combined with the MA2120 mixer amplifier.

Main Features

  • Easy setup, and a user-friendly interface for effortless operation
  • Supporting Lo-Z (120W x2ch @4? or 100W x2ch @3?/8?) and Hi-Z (120W x2ch or 200W x1ch, 70V/100V) speaker systems
  • 1 stereo/2 mono line inputs
  • Output EQ for optimizing the sound of each Output channel
  • Built-in speaker EQ optimum for Yamaha VXC/VXS series speakers, as well as HPF and selectable LPF settings
  • Capable of controlling sources and volumes seperately in two areas (Source/volume zoning)
  • Service areas or zoning areas can be expanded by adding a PA2120
  • Remote volume control and microphone on/off switching via optional DCP control panels (DCP4V4S, DCP1V4S, DCP4S, max 2 units)
  • Intelligent protection function ensures safe, reliable operation
  • Certified as Yamaha Eco Products

General Information

Name: Yamaha PA2120 Power Amplifier with 1-Stereo / 2-Mono Line Inputs, 2x120W
Category: Yamaha, Pro AV, Commercial Audio, Pro Amplifiers
UPC Code: 889025101226
Country of Origin: Indonesia. Country of origin is subject to change.

Specifications

Product Documents and Resources
