Digital Watchdog DWC-B6263WTIR650W Star-Light UHDoC 2.1MP Bullet Camera, 6-50mm Varifocal Lens
DWC-B6263WTIR650W|6K-B6263W65W
Digital Watchdog DWC-B6263WTIR650W Star-Light UHDoC 2.1MP Bullet Camera, 6-50mm Varifocal Lens
DWC-B6263WTIR650W|6K-B6263W65W
Digital Watchdog
Digital Watchdog DWC-B6263WTIR650W Star-Light UHDoC 2.1MP Bullet Camera, 6-50mm Varifocal Lens
DWC-B6263WTIR650W | 6K-B6263W65W
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Star-Light Universal HD over coax cameras deliver crystal-clear images and support real-time 30fps HD-Analog, HD-TVI, HD-CVI at 2.1MP/1080p and CVBS at 960H. The IP66-rated weather-resistant bullet cameras come with 6-50mm long range vari-focal lens, Star-Light low light technology and are engineered to work with our VMAX A1 Plus Universal HD over Coax DVRs using your existing coax infrastructure for a cost-effective, high resolution surveillance solution.
Main Features
- Universal HD over coax technology with HD-Analog, HD-TVI, HD-CVI and all analog to 960H signal support
- Star-Light super low light technology
- 2.1MP 1/3" image sensor at real-time 30fps
- 6-50mm vari-focal P-Iris lens
- True wide dynamic range (WDR)
- OSD control via coaxial (UTC)
- 150' Smart IR with intelligent camera sync
- Smart DNR 3D digital noise reduction
- True day / night with mechanical IR cut filter
- De-Fog extreme weather image compensation
General Information
Name: Digital Watchdog DWC-B6263WTIR650W Star-Light UHDoC 2.1MP Bullet Camera, 6-50mm Varifocal Lens
Category: Digital Watchdog, Video Surveillance, HDoC Cameras, Bullet Cameras
UPC Code: 812226037063
Country of Origin: VN. Country of origin is subject to change.
Specifications
ADI Part Number 6K-B6263W65W Brand Name Digital Watchdog Manufacturer Digital Watchdog Manufacturer Part Number DWCB6263WTIR650W Product Line Star-Light Plus Product Model DWC-B6263WTIR650W Product Name Star-Light 2.1MP/1080p UHDoC Bullet Camera Product Type Surveillance Camera Weight 1.83lb
American Wire Gauge 18AWG Connectivity Technology Wired Effective Camera Resolution 2MP Field of View Horizontal, Vertical Illumination Distance 150' Lens Type Varifocal Material Aluminum Die-cast Maximum Frame Rate 30fps Minimum Focal Length 6mm Motion Detection Yes Night Vision Yes Night Vision Type Infrared Optical Zoom 8.3x Output Voltage 24V AC Programmable Yes Video Formats H.264, MJPEG
Night Vision Distance 150 ft Wide Dynamic Range Yes
Image Sensor Size 1/3" Maximum Video Resolution 1920 x 1080
Minimum Operating Temperature -4°F (-20°C) Operating Humidity 10-90% (Non-condensing) Operating Temperature (T-T) -4-122°F
Longest Shutter Speed 1/30 Second Minimum Illumination 0.0 lux (B/W)|0.039 lux (color) Shortest Shutter Speed 1/30000 Second
Focal Length 6-50 mm Focus Modes Auto, Manual Lens Included Yes Maximum Focal Length 50 mm
Color White Durability Dust Resistant, Tamper Resistant, Waterproof, Weather Resistant Form Factor Bullet
Frequency 50 Hz, 60 Hz Input Voltage 12V DC, 24V AC
Recording Formats Full HD
Analog Video Signal Format CVBS, HDCVI, HDoC, HD-TVI Maximum Resolution 1280 x 720
Limited Warranty 5-Year
Certifications CE, FCC, NDAA Environmental Certification RoHS Environmentally Friendly Yes Features 3D Digital Noise Reduction, Anti-flicker, Auto Flip, Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Built-in Joystick, Day/Night, Defog, Mirror, Noise Detection, Noise Reduction, Privacy Masking, Wide Dynamic Range Ingress Protection Rating IP66
