Digital Watchdog DWC-MPH2W28TW MEGApix IVA 2.1MP Mini Pinhole IP Camera, 2.8 mm Fixed Lens, White
DWC-MPH2W28TW|6K-MPH2W28TW
Digital Watchdog DWC-MPH2W28TW MEGApix IVA 2.1MP Mini Pinhole IP Camera, 2.8 mm Fixed Lens, White
DWC-MPH2W28TW|6K-MPH2W28TW
Digital Watchdog
Digital Watchdog DWC-MPH2W28TW MEGApix IVA 2.1MP Mini Pinhole IP Camera, 2.8 mm Fixed Lens, White
DWC-MPH2W28TW | 6K-MPH2W28TW
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
This MEGApix IP camera is your gateway to powerful video analytics features. The 2.1MP/1080p pinhole IP camera is an NDAA compliant ATM camera that delivers crystal-clear real-time 30fps images at close range. The camera’s small, compact design and sturdy main body make it ideal for banks and credit unions looking for reliable and discreet surveillance at ATMs.
Main Features
- Intelligent Video Analytics reduce false alarms
- Seamless integration and control of IVA rules with DW Spectrum IPVMS
- Increase your recording storage with logic rules and smart recording
- 2.1MP/1080p ATM pinhole camera at real-time 30fps
- True Wide Dynamic Range (WDR)
- Triple codecs (H.265, H.264, MJPEG) with simultaneous streaming
- Smart DNR™ 3D digital noise reduction
- NDAA compliant
- ONVIF conformant, profile S
- 2.8mm fixed lens
General Information
Name: Digital Watchdog DWC-MPH2W28TW MEGApix IVA 2.1MP Mini Pinhole IP Camera, 2.8 mm Fixed Lens, White
Category: Digital Watchdog, Video Surveillance, IP Cameras, Covert Cameras
UPC Code: 8122260347275
Country of Origin: Korea. Country of origin is subject to change.
Specifications
ADI Part Number 6K-MPH2W28TW Brand Name Digital Watchdog Manufacturer Part Number DWC-MPH2W28TW Product Line MEGApix Product Model DWC-MPH2W28TW Product Series MPH2 Supported Network Protocols IPv4 Weight 0.92 lb
American Wire Gauge 18AWG Effective Camera Resolution 2MP Field of View Horizontal, Vertical Lens Type Fixed Maximum Frame Rate 30fps Motion Detection Yes Output Voltage 12V DC Programmable Yes Protocols DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP) Video Formats H.264, MJPEG
Image Sensor Type CMOS Wide Dynamic Range Yes
Operating Humidity 10-90% (Non-condensing) Operating Temperature (T-T) -4-122°F
Minimum Illumination 0.065 lux (color) Shortest Shutter Speed Off|x10|x2|x3|x5|x6|x7.5
Certifications CE, FCC, NDAA, UL Listing
Focal Length 2.8 mm Focus Modes Auto, Manual
Color White Form Factor Pinhole Material Aluminum Die-cast, Plastic
Limited Warranty 5-Year
