Product Overview
This NDAA/TAA-compliant MEGApix Ai IP camera provides two 5MP channels at real-time 30fps with an Ai edge engine onboard one channel, placing the power of AI deep learning object detection at your fingertips. The dual-sensor vandal dome camera offers two independently adjustable cameras in one housing for a simplified installation.
Main Features
- 2x 5MP sensors at real-time 30 fps
- Star-Light Plus color in near-total darkness technology
- AI Deep Learning object detection on one channel
- Create up to 40 separate detection zones
- Easy setup with no analytics calibration
- Seamless integration and control with DW Spectrum
- Reduce false alarms with multiple detection zones and logical rules
- Increase your recording storage with smart recording and no false alarms
- Dual-sensor vandal dome camera, two cameras in one installation
- 180° hallway and 90° corner coverage with a single camera installation
General Information
Name: Digital Watchdog DWC-PDS10WI28A MEGApix Ai 10MP IP Dual-Sensor Vandal Dome Camera, 2.8mm Fixed Lens, White
Category: Digital Watchdog, Video Surveillance, IP Cameras, Wireless Cameras, Dome Cameras
UPC Code: 812226038145
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 6K-PDS10WI28 Brand Name Digital Watchdog Manufacturer Digital Watchdog Manufacturer Part Number DWCPDS10WI28A Product Line MEGApix Ai Product Model DWC-PDS10Wi28A Product Name MEGApix Ai 10MP dual-sensor vandal dome IP camera with fixed lenses Product Type Network Camera Supported Network Protocols IPv4 Weight 1.49lb
American Wire Gauge 18AWG Built-in Microphone Yes Connectivity Technology Wired Effective Camera Resolution 10MP Field of View Horizontal, Vertical Illumination Distance 50' Lens Type Fixed Material Aluminum Die-cast Maximum Frame Rate 30fps Minimum Focal Length 2.8mm Motion Detection Yes Night Vision Yes Night Vision Type Infrared Output Voltage 12V DC Programmable Yes Protocols DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP) Video Formats H.264, H.265
Night Vision Distance 50 ft Wide Dynamic Range Yes
Image Sensor Size 1/2.8" Maximum Video Resolution 2592 x 1944 Number of Sensors 2
Maximum Operating Temperature 122°F (50°C) Minimum Operating Temperature -4°F (-20°C) Operating Humidity 10-90% (Non-condensing) Operating Temperature (T-T) -4-122°F
Longest Shutter Speed 1/15 Second Minimum Illumination 0.0 lux (B/W)|0.13 lux (color) Shortest Shutter Speed Off|x10|x2|x3|x5|x6|x7.5
Network (RJ-45) Yes
Focal Length 2.8 mm Focus Modes Auto, Manual Lens Included Yes Maximum Focal Length 2.80 mm
Remote Management Yes
Color White Durability Weather Resistant Form Factor Dome, Panoramic Height 5.5" Width 3.1"
Frequency 50 Hz Input Voltage 12V DC
Mount Type Ceiling Mount, Corner Mount, Junction Box Mount, Pendant Mount, Pole Mount, Wall Mount
Storage Type Memory Card
Analog Video Signal Format CVBS Maximum Resolution 1280 x 720
Limited Warranty 5-Year
Certifications CE, FCC, NDAA, ONVIF, TAA, UL Listing Features 3D Digital Noise Reduction, Alarm Detection, Auto Flip, Auto Gain Control, Built-in Web Server, Cross Line Detection, Day/Night, Defog, Enter/Exit Detector, Mirror, Motion Detection, SD Card Local Storage, Smart IR, Tamper Detection, Wide Dynamic Range Impact Protection Rating IK10 Ingress Protection Rating IP67 TAA Compliant Yes
