Digital Watchdog DWC-XSBA08MI MEGApix Ai 4K Bullet IP Camera with Vari-Focal Lens, IR
Digital Watchdog DWC-XSBA08MI MEGApix Ai 4K Bullet IP Camera with Vari-Focal Lens, IR
Digital Watchdog DWC-XSBA08MI MEGApix Ai 4K Bullet IP Camera with Vari-Focal Lens, IR
DWC-XSBA08MI | 6K-XSBA08MI
Please sign in to view pricing and availability and to add to cart.
Product Overview
MEGApix AI IP camera provides 4K resolution at real-time 30 fps with an AI edge engine onboard. MEGApix AI cameras place the power of AI deep learning at your fingertips, with object detection and people tracking. This camera features Star-Light Plus color in near-total darkness technology and true WDR for quality video in any lighting condition, and a 2.7-13.5mm varifocal auto-focus lens for clarity and convenience. The weather-resistant bullet camera is IP67-rated, IK10 impact-resistant and will Cold Start at -40° F/-40° C. All MEGApix cameras are ONVIF conformant, assuring their successful integration with any open platform solution on the market.
Main Features
- 4K sensor at real-time 30 fps
- Star-Light Plus color in near-total darkness technology
- AI Deep Learning object detection
- Create up to 40 separate detection zones
- Easy setup with no analytics calibration
- Seamless integration and control with DW Spectrum
- Reduce false alarms with multiple detection zones and logical rules
- Increase your recording storage with smart recording and no false alarms
- Varifocal p-iris lens with motorized zoom and autofocus for complete remote lens control and focused image any time
- True Wide Dynamic Range (WDR) for clear images in challenging light
General Information
Specifications
ADI Part Number 6K-XSBA08MI Brand Name Digital Watchdog Manufacturer Digital Watchdog Manufacturer Part Number DWCXSBA08MI Product Line MEGApix Ai Product Model DWC-XSBA08Mi Product Name MEGApix Ai 4K bullet IP camera with a vari-focal lens, IR Product Type Network Camera Supported Network Protocols IPv4 Weight 2.64lb
American Wire Gauge 18AWG Built-in Microphone Yes Connectivity Technology Wired Effective Camera Resolution 8MP Field of View Horizontal, Vertical Illumination Distance 140' Lens Type Varifocal, Zoom Material Aluminum Die-cast Maximum Frame Rate 30fps Minimum Focal Length 2.7mm Motion Detection Yes Night Vision Yes Night Vision Type Infrared Output Voltage 12V DC Programmable Yes Protocols DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP) Video Formats H.264, H.265
Night Vision Distance 140 ft Wide Dynamic Range Yes
Image Sensor Size 1/2.8" Maximum Video Resolution 2592 x 1944
Maximum Operating Temperature 122°F (50°C) Minimum Operating Temperature -40°F (-40°C) Operating Humidity 10-90% (Non-condensing) Operating Temperature (T-T) -40-122°F
Longest Shutter Speed 1/15 Second Minimum Illumination 0.0 lux (B/W)|0.09 lux (color) Shortest Shutter Speed Off|x10|x2|x3|x5|x6|x7.5
Focal Length 2.7-13.5 mm Focus Modes Auto, Manual Lens Included Yes Maximum Focal Length 13.50 mm
Remote Management Yes
Color White Durability Weather Resistant Form Factor Bullet Height 12.2" Width 3.8"
Frequency 50 Hz Input Voltage 12V DC
Mount Type Ceiling Mount, Wall Mount
Recording Formats 4K Storage Type Memory Card
Analog Video Signal Format CVBS Maximum Resolution 1280 x 720
Limited Warranty 5-Year
Certifications CE, FCC, NDAA, ONVIF, TAA, UL Listing Features 3D Digital Noise Reduction, Alarm Detection, Auto Flip, Auto Gain Control, Built-in Web Server, Cross Line Detection, Day/Night, Defog, Enter/Exit Detector, Mirror, Motion Detection, SD Card Local Storage, Smart IR, Tamper Detection, Wide Dynamic Range Impact Protection Rating IK10 Ingress Protection Rating IP67 TAA Compliant Yes
