Digital Watchdog DWC-XSBC08BI MEGApix Ai 4K Bullet IP Camera with Ultra-Wide Fixed Lens, IR and AI
DWC-XSBC08BI|6K-XSBC08BIB
Digital Watchdog DWC-XSBC08BI MEGApix Ai 4K Bullet IP Camera with Ultra-Wide Fixed Lens, IR and AI
DWC-XSBC08BI|6K-XSBC08BIB
Digital Watchdog
Digital Watchdog DWC-XSBC08BI MEGApix Ai 4K Bullet IP Camera with Ultra-Wide Fixed Lens, IR and AI
DWC-XSBC08BI | 6K-XSBC08BIB
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
This NDAA/TAA-compliant MEGApix AI ultra-wide view IP camera provides 4K resolution at real-time 30 fps with an edge AI engine onboard, placing the power of AI deep learning at your fingertips. The camera’s 2.3mm ultra-wide view lens offers edge-to-edge image clarity without pixel loss and is ideal for wide-area situational awareness.
Main Features
- 4K sensor at real-time 30 fps
- Star-Light Plus color in near-total darkness technology
- AI Deep Learning object detection
- Create up to 40 separate detection zones
- Easy setup with no analytics calibration
- Seamless integration and control with DW Spectrum
- Reduce false alarms with multiple detection zones and logical rules
- Increase your recording storage with smart recording and no false alarms
- 2.3mm ultra-wide view lens for edge-to-edge image clarity without pixel loss
- True Wide Dynamic Range (WDR) for clear images in challenging light
General Information
Name: Digital Watchdog DWC-XSBC08BI MEGApix Ai 4K Bullet IP Camera with Ultra-Wide Fixed Lens, IR and AI
Category: Digital Watchdog, Video Surveillance, IP Cameras, Panoramic Cameras
UPC Code: 812226039210
Country of Origin: KR. Country of origin is subject to change.
Specifications
ADI Part Number 6K-XSBC08BIB Brand Name Digital Watchdog Manufacturer Part Number DWC-XSBC08BI Product Line MEGApix Ai Product Name MEGApix Ai 4K bullet IP camera with ultra-wide fixed lens, IR and an AI engine Product Type IP Camera Supported Network Protocols IPv4 Weight 2.13lb
American Wire Gauge 18AWG Built-in Microphone Yes Effective Camera Resolution 8MP Field of View Horizontal, Vertical Illumination Distance 100' Lens Type Fixed Material Aluminum Die-cast Maximum Frame Rate 30fps Motion Detection Yes Night Vision Yes Output Voltage 12V DC Protocols DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP) Video Formats H.264, H.265
Wide Dynamic Range Yes
Image Sensor Size 1/1.8" Maximum Video Resolution 2592 x 1944
Maximum Operating Temperature 122°F Minimum Operating Temperature -4°F Operating Humidity 10-90% (Non-condensing) Operating Temperature (T-T) -40-122°F
Longest Shutter Speed 1/15 Second Minimum Illumination 0.0 lux (B/W)|0.15 lux (color) Shortest Shutter Speed Off|x10|x2|x3|x5|x6|x7.5
Focal Length 2.3 mm Focus Modes Auto, Manual Lens Included Yes Maximum Focal Length 2.3 mm
Depth 3.8" Durability Weather Resistant Form Factor Bullet, Panoramic Height 5.03" Width 8.75"
Frequency 50 Hz Input Voltage 12V DC
Limited Warranty 5-Year
Certifications CE, FCC, NDAA, ONVIF, TAA, UL Listing Impact Protection Rating IK09 Ingress Protection Rating IP67
