Product Overview
This NDAA/TAA-compliant MEGApix AI turret IP camera provides 5MP resolution at real-time 30 fps with 90ft range white light and red/blue flash LEDs built-in and an edge AI engine onboard. The camera features Star-Light Plus color in near-total darkness technology and built-in microphone and speaker in an IP67-rated, IK10 rated housing.
Main Features
- 5MP sensor at real-time 30 fps
- Star-Light Plus color in near-total darkness technology
- AI Deep Learning object detection
- Create up to 40 separate detection zones
- Easy setup with no analytics calibration
- Seamless integration and control with DW Spectrum
- Reduce false alarms with multiple detection zones and logical rules
- Increase your recording storage with smart recording and no false alarms
- 90' white light illumination and red/blue flash LEDs for video, illumination and deterrence in a single camera installation
- Vari-focal p-iris lens with motorized zoom and autofocus for complete remote lens control and focused image any time
General Information
Name: Digital Watchdog DWC-XSTD05MF MEGApix Ai 5MP Vandal Ball Turret IP Camera with White Light LEDs, 2.7-12mm Varifocal Lens
Category: Digital Watchdog, Video Surveillance, IP Cameras, Turret Cameras
UPC Code: 812226039227
Country of Origin: KR. Country of origin is subject to change.
Specifications
American Wire Gauge 18AWG Built-in Microphone Yes Effective Camera Resolution 5MP Field of View Horizontal, Vertical Lens Type Varifocal, Zoom Material Aluminum Die-cast Maximum Aperture f/1.3 Maximum Frame Rate 30fps Minimum Focal Length 2.7mm Motion Detection Yes Night Vision Yes Output Voltage 12V DC Programmable Yes Protocols DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP) Video Formats H.264, H.265
Wide Dynamic Range Yes
Image Sensor Size 1/2.8" Maximum Video Resolution 2592 x 1944
Maximum Operating Temperature 122°F Operating Humidity 10-90% (Non-condensing) Operating Temperature (T-T) -4-122°F
Longest Shutter Speed 1/15 s Minimum Illumination 0 lux (white light)|0.03 lux (color) Shortest Shutter Speed Off|x10|x2|x3|x5|x6|x7.5
HDMI No
Focal Length 2.7-12 mm Focus Modes Auto, Manual Lens Included Yes Maximum Focal Length 12 mm
Color White Durability Weather Resistant Form Factor Turret Height 4.8"
Frequency 50 Hz Input Voltage 12V DC
Mount Type Ceiling Mount, Corner Mount, Junction Box Mount, Pole Mount, Wall Mount
Limited Warranty 5-Year
Certifications CE, FCC, NDAA, ONVIF, TAA, UL Listing Environmental Certification CE, FCC Environmentally Friendly Yes Impact Protection Rating IK10 Ingress Protection Rating IP67 TAA Compliant Yes
