Product Overview
The CM62-EZs-II is a 6.5-inch, coaxial, two-way, blind-mount, in-ceiling speaker which delivers true high efficiency and performance across the operating bandwidth. By incorporating a 6.5" treated-fiber driver with cloth surround in a sealed drawn-steel backcan, this speaker delivers maximum frequency response (75-22 kHz, - 10 dB) in a compact design.
Main Features
- Incorporates a painted steel grille for lasting durability
- Superior voice intelligibility with a 10 kHz coverage angle of 80° (independently verified)
- Easy-access six-position tap switch for 25/70.7/100V and 16omhs transformer bypass position allows for easy ordering, stocking and installation
- Reduced amplification costs with maximum efficiency including 90.5 dB sensitivity and 16 ohms impedance
- One 6.50" (165.0mm) treated fiber woofer with cloth surround and one 1.00" (25.4mm) silk dome tweeter
- Engineered for applications with limited plenum space, incorporating a SoundTube-specific shallow backcan with an installed depth of only 3.5"
General Information
Name: SoundTube CM62-EZS-II-WH 6" 2-Way In-Ceiling Speaker with White Seamless Magnetic Grille with Short Can
Category: SoundTube, Residential AV, Pro AV, Residential Audio, Commercial Audio, Speakers, Pro Speakers
UPC Code: 752830442689
Country of Origin: CN. Country of origin is subject to change.
Specifications
ADI Part Number 9W-CM62ZSIIW Brand Name SoundTube Manufacturer SoundTube Manufacturer Part Number CM62EZSIIWH Product Model CM62-EZs-II Product Name CM62-EZS-II Speaker Product Type Speaker
Crossover Type 2-way Impedance 16 ohms Material Fiber Cone Sensitivity 90dB
Maximum Frequency Response 22 kHz Minimum Frequency Response 75Hz RMS Output Power 50W
Sound Emission 10 dB|5 dB
Application/Usage Alarm, Voice Color White Enclosure Type Sealed Form Factor Blind Mount, Ceiling Mount, In-ceiling Height 0.3" Size 6.50"
Diameter 11.8" Mount Type Blind Mount, Ceiling Mount, In-Ceiling Mount
Limited Warranty 5-Year
Environmental Certification RoHS, WEEE Environmentally Friendly Yes Package Contents - CM62-EZS-II Speaker
- Conduit Clamp
- Cover Plate
- Grille
- Paint Mask
- Choose Between a Tile Bridge or Pre-Construction Bracket
TAA Compliant No
