AMX FG1010-325-WHFX Multi-Format Decor Style Wall Plate Transmitter, White
FG1010-325-WHFX|AI-1010325WH
AMX FG1010-325-WHFX Multi-Format Decor Style Wall Plate Transmitter, White
FG1010-325-WHFX|AI-1010325WH
AMX by Harman
AMX FG1010-325-WHFX Multi-Format Decor Style Wall Plate Transmitter, White
FG1010-325-WHFX | AI-1010325WH
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The AMX FG1010-325-WHFX Multi-Format Decor Style Wall Plate Transmitter in white offers a streamlined solution for audio and video transmission over a single twisted pair cable, also delivering power efficiently. It supports a variety of signals including legacy analog formats like RGBHV, Component, S-Video, Composite, and digital signals such as HDMI/HDCP, DisplayPort++, and DVI. Capable of extending HDMI signals up to 100 meters, it surpasses the typical range of standard HDMI cables. Installation is simplified with standard twisted pair cabling and compatibility with standard decor style wallplates. This transmitter is designed for seamless integration with Enova DGX or DVX systems and features Power over DXLink capabilities, allowing direct connection to DXLink receivers for convenient point-to-point setups. Upgrade your AV setup effortlessly with this versatile and easy-to-install wall plate transmitter.
Main Features
- Only One Cable Send audio and video, while passing power over one twisted pair cable
- Multi-Format Analog Port and HDMI Port Supports legacy analog signals-RGBHV, Component, S-Video, and Composite, and digital HDMI/HDCP, DisplayPort++ and DVI signals
- Send HDMI signals up to 100 meters Extend the reach of the HDMI signals far beyond the capabilities of typical HDMI cabling
- Standard Twisted Pair Cable Save time and effort in installation by leveraging cost effective twisted pair cable, see the Cabling for Success with DXLink white paper for more details
- Easy Installation Mounts in standard decor style wallplates
- Power over DXLink Enabled Designed for use with Enova DGX or DVX systems with DXLink inputs, or PS-POE-AT-TC (FG423-84) or PDXL-2 (FG1090-170) to provide remotely located Power over DXLink (requires firmware v1.2.40 or above)
- DXLink Direct Connection When receiving Power over DXLink from the PS-POE-AT-TC or PDXL-2, DXLink Wallplates can be connected directly to a DXLink Receiver for a point-to-point solution
General Information
Name: AMX FG1010-325-WHFX Multi-Format Decor Style Wall Plate Transmitter, White
Category: AMX by Harman, Pro AV, Commercial Audio, Pro Accessories & Mounts
UPC Code: 718878246221
Country of Origin: US. Country of origin is subject to change.
Specifications
ADI Part Number AI-1010325WH Brand Name AMX by Harman Manufacturer AMX by Harman Manufacturer Part Number FG1010-325-WHFX Product Model DX-TX-DWP Product Name DXLink Multi-Format Decor Style Wallplate Transmitters Product Type Wallplate Transmitters
Color White Depth 2-1/4" Height 4-1/16" Width 3.5"
Features DXLink Direct Connection When receiving Power over DXLink from the PS-POE-AT-TC or PDXL-2, DXLink Wallplates can be connected directly to a DXLink Receiver for a point-to-point solution, Easy Installation Mounts in standard decor style wallplates, Multi-Format Analog Port and HDMI Port Supports legacy analog signals-RGBHV, Component, S-Video, and Composite, and digital HDMI/HDCP, DisplayPort++ and DVI signals, Only One Cable Send audio and video, while passing power over one twisted pair cable, Power over DXLink Enabled Designed for use with Enova DGX or DVX systems with DXLink inputs, or PS-POE-AT-TC (FG423-84) or PDXL-2 (FG1090-170) to provide remotely located Power over DXLink (requires firmware v1.2.40 or above), Send HDMI signals up to 100 meters Extend the reach of the HDMI signals far beyond the capabilities of typical HDMI cabling, Standard Twisted Pair Cable Save time and effort in installation by leveraging cost effective twisted pair cable, see the Cabling for Success with DXLink white paper for more details
