Honeywell Home IS3035V Wired PIR Motion Detector (Replaces IS2535)
Honeywell Home IS3035V Wired PIR Motion Detector (Replaces IS2535)
Honeywell Home IS3035V Wired PIR Motion Detector (Replaces IS2535)
IS3035V | CK-IS3035V
Please sign in to view pricing and availability and to add to cart.
Product Overview
Designed with the installer in mind, these high performance small form factor motion detectors offer a trouble-free, out of the box experience to simplify the install process and reduce install time. With the passive infrared IS3035 and IS3050 and DUAL TEC DT8035 and DT8050, optimum performance is achieved using custom developed extended range Fresnel optics, look down, cover and wall tamper, and selectable pet immunity. Leading edge sensing technologies and a wide range of models to suit the requirements of most applications, Honeywell Home family of IS3000 and DT8000 motion detectors will maximize intruder detection while diminishing false alarms.
Main Features
- Hardwired Motion Detection Sensor
- Passive Infrared (PIR)
- 4-Wire
- 9VDC to 15VDC power rating
- Up to 40' by 56' (12m to 17m) coverage
- 102 total detection zones
- PIR white light immunity ~6,500 Lux
- 6 screw terminals
- Operating Temperature: 14°F to 131°F (-10°C to 55°C)
- UL, ULc, SIA
General Information
Specifications
ADI Part Number CK-IS3035V Brand Name Honeywell Home Manufacturer Resideo Manufacturer Part Number IS3035V Product Model IS3035V Product Name IS3035V Motion Sensor Product Series IS3000 Product Type Motion Sensor Weight 3oz
Connectivity Technology Wireless Maximum Motion Sensing Distance 56' Maximum Time Delay 3-Second Minimum Motion Sensing Distance 40' Passive Infrared Sensor (PIR) Yes
Minimum Operating Temperature 14°F
Application/Usage Motion Detection for Security Systems Color White Depth 1.71" Height 3.9" Width 2.2"
Input Voltage 15V DC Power Source DC Power
Mount Type Wall Mount
Certifications & Standards ANSR UL639: Intrusion-detection Units, ULC S306-03: Equipment Intrusion-detection Unit Compatibility Security Systems Environmental Certification UL Features Pet-Tolerance Indoor/Outdoor Indoor
