TP-Link DS108GP Omada Unmanaged 8-Port Gigabit Desktop Switch with 8-Port PoE+
TP-Link DS108GP Omada Unmanaged 8-Port Gigabit Desktop Switch with 8-Port PoE+
TP-Link DS108GP Omada Unmanaged 8-Port Gigabit Desktop Switch with 8-Port PoE+
DS108GP | FP-DS108GP
Please sign in to view pricing and availability and to add to cart.
Product Overview
Power over Ethernet, Flexible Network Deployment Compliant with the IEEE 802.3af/at PoE standards, the switch supports a total PoE power budget of 65W with 30W max per PoE+ port. When total power consumption exceeds 65W, the intelligent power management will cut the lower priority ports power to protect devices from damage. Instantaneous Multi-mode Toggles. Extend mode; Up to 250m Transmissions With extend mode, the PoE transmission distance reaches up to 250m, perfect for IP Camera deployment in large areas. Recovery mode; PoE Auto Recovery Recovery mode helps automatically detect and reboot PD devices, such as cameras and APs, when they fall offline or go unresponsive, all without needing manual monitoring and restarts.
Main Features
- 8x 10/100/1000 Mbps RJ45 ports
- 8x PoE+ ports transfer data and power on individual cables
- Works with IEEE 802.3af/at compliant PDs
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
- Supports PoE power up to 30W for each PoE port
- Supports PoE power up to 65W for all PoE ports
- Up to 250m (820ft) data and power transmitting range under Extend Mode
- PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
- Plug and Play. No configuration or central management required.
General Information
Specifications
ADI Part Number FP-DS108GP Brand Name TP-Link Manufacturer TP-LINK Technologies Co., Ltd Manufacturer Part Number DS108GP Product Line Omada Product Name Omada 8-Port Gigabit Desktop Switch with 8-Port PoE+ Product Type Switch
Material Metal Media Type Supported Twisted Pair Power Consumption 74.39W
Total Number of Network Ports 8
Manageable No
Network Technology 10/100/1000Base-T
Ethernet Technology 10 Gigabit Ethernet Networking Standards IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Color Black Form Factor Desktop, Wall Mount Height 1" Package Type Box Width 4"
Input Voltage 53.5V DC PoE (RJ-45) Port Yes Power Source DC, PoE, Power Adapter
Length 6.2" Mount Type Desktop Mount, Wall Mount
Environmental Certification CE, FCC, RoHS Environmentally Friendly Yes Features Fanless Package Contents DS108GP, Installation guide, Power Adapter TAA Compliant No
