Product Overview
The MC220L is a media converter designed to convert 1000BASE-SX/LX/LH fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-SX/LX/LH standards, the MC220L is designed for use with multi-mode/single-mode fiber cable utilizing the SC/LC-Type connector. It works at 850nm on both transmitting and receiving data when adopting multi-mode fiber and 1310nm on both transmitting and receiving data when adopting single-mode.
Main Features
- Convert Fiber to Ethernet: Designed to convert 1000BASE-SX/LX fiber to 1000Base-T copper media or vice versa.
- Versatile Compatibility:Works with both single-mode and multi-mode fiber SFP modules and is fully compatible with 10/100/1000 Base-T Ethernet connections.
- Easy to Use: Plug and play with no software installation or configuration needed.
- Auto-Negotiation Gigabit Connection: Auto-negotiation RJ45 port supports Half-Duplex/Full-Duplex transfer mode and auto-MDI/MDIX.
- Long-Range Transmission: When used with different types of SFP modules, the Hot-Swappable FX Port extends fiber distance up to 12.4miles (20km) for Single-Mode transmission and 1,800 feet (550m) for Multi-Mode transmission.
General Information
Name: TP-Link TL-MC220L Gigabit Ethernet Media Converter
Category: TP-Link, Data Comm & Networking, Media Converters & Transceivers, Media Converters
UPC Code: 845973030476
Country of Origin: VN. Country of origin is subject to change.
Specifications
ADI Part Number FP-MC220L Brand Name TP-Link Manufacturer TP-LINK Technologies Co., Ltd Manufacturer Part Number MC220L Product Model MC220L Product Name MC220L Gigabit Ethernet Media Converter Product Type Transceiver/Media Converter
Media Type Supported Optical Fiber Power Consumption 1.70W
Expansion Slot Type SFP Number of SFP Slots 1 Number of SFP+ Slots 1 Number of Total Expansion Slots 1
Network (RJ-45) Yes Number of Network (RJ-45) Ports 1
Network Technology 1000Base-T
Ethernet Technology Gigabit Ethernet
Depth 2.9" Form Factor External Height 1.1" Width 3.7"
Power Source Power Adapter
Environmentally Friendly Yes Package Contents - MC220L Gigabit Ethernet Media Converter
- Power Adapter
- Installation Guide
