Simply45 S45-1501P Pro Series CAT5e Unshielded, Pass-Through RJ45 with Cap45, 100-Piece
Simply45 S45-1501P Pro Series CAT5e Unshielded, Pass-Through RJ45 with Cap45, 100-Piece
Simply45 S45-1501P Pro Series CAT5e Unshielded, Pass-Through RJ45 with Cap45, 100-Piece
S45-1501P | G0-S451501P
Please sign in to view pricing and availability and to add to cart.
Product Overview
Simply45 is the industry-leading brand for RJ45 modular plug innovation and performance solutions. Our S45-1501P is the same as our S45-1500P except is packaged in a convenient 50-piece plastic clamshell. The Simply45 ProSeries introduces the exclusive Cap45 (PATENT 10,811,831 B1). Cap45® is an isolation cap/bar that snaps onto the front of the pass-through RJ45 plug after termination, covering the exposed wire ends. Cap45 prevents electrical shorting in the RJ45 socket due to improperly trimmed wires or in device sockets that may not be 100% compliant. With Cap45, any electrical risks associated with exposed wire ends are now eliminated completely.
Main Features
- Pass Through with Cap45
- 24AWG Solid , 28-26AWG Stranded
- Conductor Range 0.95 – 1.05mm (0.037″ – 0.041″)
- Max Cable OD 6.5mm (0.255″)
- UL94 V0 Commercial (Plenum, LSZH) Rated
- Blue Tint
- 3 Prong Style
- 50µ 24ct Gold
- Wide Mouth Jar for Easy Hand Access
- Color-Coded Jar Caps
General Information
Specifications
ADI Part Number G0-S451501P Brand Name Simply45 Manufacturer SIMPLY45 LLC Manufacturer Part Number S45-1501P Packaged Quantity 50 Product Line Simply45 Product Model S45-1501P Product Name Pro Network Connector Product Series ProSeries Product Type Network Connector Weight 4oz
Cable Type Category 5e Contact Plating Gold Shielding No
Connector Type RJ45 Network Male Number of Contacts 8
Color Blue Package Type Clamshell
Limited Warranty Lifetime
Environmentally Friendly Yes Features 3 Prong Contact, 50µ Gold, Color Tinted, Crosstalk Protection, Far End Cross Talk (FEXT), Fire Retardant, HDBaseT, Near End Cross Talk (NEXT), Plenum, PoE, PoE+, PoE++, Polycarbonate, Solid, Stranded Package Contents - PRO Network Connector
- 55 x Caps
TAA Compliant Yes
