ICC IC1076VTWH Keystone Jack
IC1076VTWH | H2-1076VTWH
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The EZ voice modular jacks, RJ-11 keystone jacks 6-Position 6-Conductor (6P6C), is designed for business system applications. The modular jacks utilize IDC termination, accepts 22-24AWG solid wire. Termination can be done using 110 punch down tool, or by using the Jackeasy termination tool for fast and easy termination. For use with applications, Apple Talk, Voice, and Arcnet. Compatible with RJ11/14 and 25 keystone jacks and plugs.
Main Features
- Designed for all voice connectivity applications
- Lead frame technology provides maximum performance
- Terminate with 110 punch down tool
- Includes an integrated USOC/UTP color wiring diagram
- Works with all Work Area Outlets faceplates, inserts, surface mount boxes
- Works with all telephone line cords
- Installation instructions included
- UL Listed
General Information
Name: ICC IC1076VTWH Keystone Jack
Category: ICC, Data Comm & Networking, Cable Connectors, Keystone Jacks
UPC Code: 633758095440
Country of Origin: Taiwan. Country of origin is subject to change.
Specifications
ADI Part Number H2-1076VTWH Brand Name ICC Manufacturer Part Number IC1076VTWH Packaged Quantity 10 Product Name Voice RJ11 Keystone Jack for EZ Style Product Series EZ Product Type Phone Connector
Cable Type Category 3 Contact Plating Gold, Nickel, Phosphor Bronze
Connector Type RJ11 Phone Female Number of Contacts 10
Country of Origin TW Environmental Certification RoHS Features Lead frame technology provides maximum performance and superior signal quality, Terminate with 110 punch down tool ICACSPDT00, Works with ICC telephone line cords
