Pass & Seymour 5862-I Receptacle Duplex 20A 250V Screw and Brass Wire, Ivory
5862-I|H4-5862I
Pass & Seymour 5862-I Receptacle Duplex 20A 250V Screw and Brass Wire, Ivory
5862-I|H4-5862I
Pass & Seymour by Legrand
Pass & Seymour 5862-I Receptacle Duplex 20A 250V Screw and Brass Wire, Ivory
5862-I | H4-5862I
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The Pass & Seymour 5862-I duplex receptacle by Legrand is designed for durability with its heavy-duty brass strap that enhances strength and grounding. The strap tabs securely wrap and lock to the face, preventing separation from the face and back body. It features an accessible break-off, line-contact tab for quick split-circuit wiring and a durable high-strength nylon face. Equipped with an internal screw-pressure-plate for versatile wiring and an auto-ground clip for reliable grounding. It operates safely within a temperature range of -40°C to 60°C and withstands high temperature rise during overloads. Upgrade your wiring with this robust and reliable receptacle today!
Main Features
- Heavy-duty, brass strap for added strength and ground conductivity
- Strap tabs wrap around and lock down on face to prevent strap from separating from face and back body
- Strap tabs wrap around face to prevent strap from separating from face and back body
- Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring
- High strength nylon face
- Internal screw-pressure-plate back and side wired to accept #14 and #10 AWG stranded or solid copper or copper-clad conductors
- Auto-ground clip assures positive ground
- Temperature Rise; Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature; Maximum continuous 60°C, minimum -40°C without impact
General Information
Name: Pass & Seymour 5862-I Receptacle Duplex 20A 250V Screw and Brass Wire, Ivory
Category: Pass & Seymour by Legrand, Batteries & Power Supplies, Electrical Plugs & Connectors, Single & Duplex Outlets
UPC Code: 785007549034
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number H4-5862I Brand Name Pass & Seymour by Legrand Manufacturer Part Number 5862-I Product Name 20A 250V Heavy Duty Spec-Grade Duplex Receptacle, Back and Side Wire, Ivory Product Type Duplex Receptacle
Color Ivory Depth 0.78" Height 2.63" Width 1.32"
Current Rating 20A Voltage Rating 250V
Certifications & Standards CSA C22.2 No. 42, cULus UL498 Country of Origin MX Environmental Certification UL94 V2
