Pass & Seymour 5862-RED Outlet, Duplex 20A 250V S+B Wire, Red
5862-RED|H4-5862RED
Pass & Seymour 5862-RED Outlet, Duplex 20A 250V S+B Wire, Red
5862-RED|H4-5862RED
Pass & Seymour by Legrand
Pass & Seymour 5862-RED Outlet, Duplex 20A 250V S+B Wire, Red
5862-RED | H4-5862RED
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The Pass & Seymour 5862-RED duplex receptacle by Legrand offers robust performance with a heavy-duty brass strap enhancing strength and ground conductivity. Its innovative strap tabs securely lock the face and back body together, preventing separation. Featuring an easily accessible break-off tab for quick split-circuit wiring and a durable nylon face, this receptacle is built for reliability. It includes a screw-pressure-plate back and side wiring compatible with #14 and #10 AWG copper conductors, plus an auto-ground clip for assured grounding. Designed to withstand up to 30°C temperature rise at full load and operate in temperatures from -40°C to 60°C, it ensures safe and stable performance. Upgrade your electrical setup with this dependable and efficient receptacle today!
Main Features
- Heavy-duty, brass strap for added strength and ground conductivity
- Strap tabs wrap around and lock down on face to prevent strap from separating from face and back body
- Strap tabs wrap around face to prevent strap from separating from face and back body
- Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring
- High strength nylon face
- Internal screw-pressure-plate back and side wired to accept #14 and #10 AWG stranded or solid copper or copper-clad conductors
- Auto-ground clip assures positive ground
- Temperature Rise; Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature; Maximum continuous 60°C, minimum -40°C without impact
General Information
Name: Pass & Seymour 5862-RED Outlet, Duplex 20A 250V S+B Wire, Red
Category: Pass & Seymour by Legrand, Batteries & Power Supplies, Electrical Plugs & Connectors, Single & Duplex Outlets
UPC Code: 785007549041
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number H4-5862RED Brand Name Pass & Seymour by Legrand Manufacturer Part Number 5862-RED Product Name 20A 250V Heavy Duty Spec-Grade Duplex Receptacle, Back and Side Wire, Red Product Type Duplex Receptacle
Color Red Depth 0.78" Height 2.63" Width 1.32"
Current Rating 20A Voltage Rating 250V
Certifications & Standards CSA C22.2 No. 42, cULus UL498 Country of Origin MX Environmental Certification UL94 V2
