Pass & Seymour 8200-RED Outlet, HOSP GRD Duplex Receptacle15A/125VA and 15A/125V Red
8200-RED|H4-8200RED
Pass & Seymour 8200-RED Outlet, HOSP GRD Duplex Receptacle15A/125VA and 15A/125V Red
8200-RED|H4-8200RED
Pass & Seymour by Legrand
Pass & Seymour 8200-RED Outlet, HOSP GRD Duplex Receptacle15A/125VA and 15A/125V Red
8200-RED | H4-8200RED
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The Pass & Seymour 8200-RED hospital grade duplex receptacle is designed for dependable performance with a one-piece nickel-plated brass strap featuring an integral ground. Its strap tabs secure firmly to prevent separation from the face and back body, enhanced by two drive screws anchoring the assembly. It includes a patented permanent circuit label on the face for easy identification. The receptacle offers durable triple-wipe power contacts for strong retention, a convenient break-off line-contact tab for quick split-circuit wiring, and oversized #10 tri-drive brass screws. Installation is simplified by patented external screw-pressure-plate clamps on terminals, ensuring a secure and visible connection. Compatible with various wall plates including TradeMaster unbreakable, radiant screwless, and metal options. Upgrade your electrical setup with this reliable and easy-to-install receptacle today!
Main Features
- One-piece nickel-plated brass mounting strap with integral ground
- Strap tabs wrap around and lock down on face to prevent strap from separating from face and back body
- Two drive screws anchor strap to back body and face
- Exclusive patented feature, circuit label on face allows permanent circuit identification
- 0.040 inch thick, nickel-plated brass, triple-wipe power contacts for lasting retention
- Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring
- Oversized #10 deep tri-drive head brass terminal and ground screws
- Exclusive patented feature, external screw-pressure-plate back wire clamp on ground terminal for faster, easier installation
- External nickel-plated screw-presure-plate back wire clamps with #10 brass terminal screws for visual assurance of a good connection
- For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here
General Information
Name: Pass & Seymour 8200-RED Outlet, HOSP GRD Duplex Receptacle15A/125VA and 15A/125V Red
Category: Pass & Seymour by Legrand, Batteries & Power Supplies, Electrical Plugs & Connectors, Single & Duplex Outlets
UPC Code: 785007820102
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number H4-8200RED Brand Name Pass & Seymour by Legrand Manufacturer Part Number 8200-RED Product Name 15A 125V Extra Heavy Duty Hospital-Grade Duplex Receptacle, Back and Side Wire, Red Product Type Duplex Receptacle
Color Red Depth 0.866" Height 2.75" Width 1.63"
Current Rating 15A Voltage Rating 125V
Certifications & Standards CSA C22.2 No. 42, cULus UL498 Country of Origin MX Environmental Certification UL94 V2, UL94-5 VA
