Pass & Seymour PT5362-SC 20A 125V Split Circuit Duplex Specification Grade, 20A, Brown
PT5362-SC|H4-PT5362SC
Pass & Seymour PT5362-SC 20A 125V Split Circuit Duplex Specification Grade, 20A, Brown
PT5362-SC|H4-PT5362SC
Pass & Seymour by Legrand
Pass & Seymour PT5362-SC 20A 125V Split Circuit Duplex Specification Grade, 20A, Brown
PT5362-SC | H4-PT5362SC
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
PlugTail Split Circuit Spec Grade Receptacles, 20A, 125A.
Main Features
- 0.036" Thick, brass, triple-wipe power contacts for lasting retention
- Plated steel wrap strap design for maximum durability and corrosion resistance
- No exposed terminals create a finger safe application before, during, and after installation
- Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections
- Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing
- Crimped and welded contacts
- Large brass contacts snugly terminate on device blade terminals
- Pre-stripped connector leads fasten to conductors, easier than standard pigtails
- Pre-wired with one welded pre-stripped wire lead to facilitate switched receptacle circuit applications
- Auto-ground clip assures positive ground
General Information
Name: Pass & Seymour PT5362-SC 20A 125V Split Circuit Duplex Specification Grade, 20A, Brown
Category: Pass & Seymour by Legrand, Batteries & Power Supplies, Electrical Plugs & Connectors, Single & Duplex Outlets
UPC Code: 785007000214
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number H4-PT5362SC Brand Name Pass & Seymour by Legrand Manufacturer Part Number PT5362-SC Product Line Pass & Seymour Product Name PlugTail Split Circuit Spec Grade Receptacles, 20A, 125V, Brown Product Type Receptacle
Color Brown Depth 0.78" Height 2.63" Width 1.32"
Current Rating 20A Voltage Rating 125V
Country of Origin MX Environmental Certification UL
