Farenhyt IDP-ISO Line Isolator Module
IDP-ISO|I2-IDPISO
Farenhyt IDP-ISO Line Isolator Module
IDP-ISO|I2-IDPISO
Honeywell Farenhyt Series
Farenhyt IDP-ISO Line Isolator Module
IDP-ISO | I2-IDPISO
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The IDP-ISO is a SLC loop line isolator module for use with the Honeywell Farenhyt Series fi re alarm control panels (FACPs). The IDP-ISO acts as an automatic switch that opens when the line voltage on the signaling line circuit (SLC) loop drops below four volts. Isolator modules should be spaced between groups of sensors or modules in a loop to protect the rest of the loop
Main Features
- Isolates short circuits on an SLC loop
- Protects the modules on the SLC loop so other devices continue to operate
- Panel controlled status LED that flashes green in normal state and is solid red in alarm
- Standard 4 inch electrical box mounting
- SEMS screws for easy wiring
General Information
Name: Farenhyt IDP-ISO Line Isolator Module
Category: Honeywell Farenhyt Series, Fire, Fire Control Panels, Control Panel Modules
UPC Code: 783863027703
Country of Origin: MX. Country of origin is subject to change.
Specifications
ADI Part Number I2-IDPISO Brand Name Honeywell Farenhyt Series Manufacturer Part Number IDP-ISO
Color Green, Red
Compatibility IFP-100 / IFP-100ECS, IFP-1000 / IFP-1000ECS, IFP-2000 / IFP-2000ECS / RPS-2000, IFP-2100 / IFP-2100ECS / RFP-2100, IFP-300 / IFP-300ECS, IFP-50, IFP-75 Environmental Certification UL Environmentally Friendly Yes
