Product Overview
The IDP-MONITOR-2 is an addressable monitor module with two initiating circuits for use with Honeywell Farenhyt Series fire alarm control panels (FACPs). The IDP-MONITOR-2 acts as an interface to contact devices, such as waterflow switches and pull stations. The IDP-MONITOR-2 supports Class B supervised wiring to the load device. Conventional 4-wire smoke detectors can be monitored for alarm and trouble conditions. Because the IDP-MONITOR-2 is capable of monitoring two separate Class B circuits, it is ideal for waterflow tamper switch and flow switch monitoring.
Main Features
- Monitor two circuits, with unique addresses,simultaneously
- Support for Class B wiring
- Fully supervised
- Panel controlled status LED that flashes green in normal state and is solid red in alarm
- Rotary address switches for fast installation
- SEMS screws for easy wiring
General Information
Name: Farenhyt IDP-MONITOR-2 Addressable Dual Monitor Module
Category: Honeywell Farenhyt Series, Fire, Fire Control Panels, Control Panel Modules
UPC Code: 783863027710
Country of Origin: MX. Country of origin is subject to change.
Specifications
ADI Part Number I2-IDPMONIR2 Brand Name Honeywell Farenhyt Series Manufacturer Part Number IDP-MONITOR-2
Color Green, Red
