Farenhyt IDP-ZONE Addressable Zone Interface Module
Farenhyt IDP-ZONE Addressable Zone Interface Module
Farenhyt IDP-ZONE Addressable Zone Interface Module
IDP-ZONE | I2-IDPZONE
Please sign in to view pricing and availability and to add to cart.
Product Overview
The IDP-ZONE is an intelligent two-wire interface module for use with Honeywell Farenhyt Series fire alarm control panels (FACPs). The IDP-ZONE allows a Farenhyt FACP to interface and monitor two-wire conventional smoke detectors. The IDP-ZONE is addressed through the signaling line circuit loop of the FACP. It transmits the status of one full zone of two-wire detectors to the FACP. Status conditions are reported as normal, open, or alarm. The IDP-ZONE supervises the zone of detectors and the connection of the external power supply. All two-wire detectors being monitored must be UL compatible with the IDP-ZONE.
Main Features
- Converts a conventional two-wire loop to an SLC loop
- Fully supervised
- Support for Style B and Style D wiring
- Panel controlled status LED that flashes green in normal state and is solid red in alarm
- Rotary address switches for fast installation
- SEMS screws for easy wiring
- UL Listed
General Information
Specifications
ADI Part Number I2-IDPZONE Brand Name Honeywell Farenhyt Series Manufacturer Part Number IDP-ZONE
Color Green, Red
Environmental Certification UL Environmentally Friendly Yes Features Attractive ivory cover plate, Converts a conventional two-wire loop to an SLC loop, Fully supervised, Rotary address switches for fast installation, SEMS screws for easy wiring, Support for Style B and Style D wiring
