JBL Professional AC566-WH Application Engineered 2-way,250W,Wall Mount
AC566|JF-AC566WH
JBL Professional AC566-WH Application Engineered 2-way,250W,Wall Mount
AC566|JF-AC566WH
JBL Professional
JBL Professional AC566-WH Application Engineered 2-way,250W,Wall Mount
AC566 | JF-AC566WH
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Applications:
- Performing Spaces
- Clubs & Bars
- Houses of Worship
- Multi Media Spaces
- Retail & Hospitality Spaces
- Presentation Suites
- Educational Facilities
The cabinet is fitted with M10 threaded suspension points. Four threaded inserts located on back of the enclosure allow attachment of a MultiMount® or similar type mounting.
AC566 is part of JBL's AE Application Engineered Series, a versatile family of loudspeakers for a wide variety of fixed installation applications.
Main Features
- Robust 15 mm enclosure with black textured finish
- 384 mm (15 in) LF transducer
- 60 deg x 60 deg Waveguide with a 25 mm (1 in) exit 35 mm (1.5") diaphragm compression driver
- Dual Neutrik NL4 connectors plus screw terminals
- Multiple attachment points for ultimate flexibility
General Information
Name: JBL Professional AC566-WH Application Engineered 2-way,250W,Wall Mount
Category: JBL Professional, Pro AV, Commercial Audio, Pro Speakers
UPC Code:
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number JF-AC566WH Brand Name JBL Professional Manufacturer Harman International Industries, Inc Manufacturer Part Number AC566-WH Product Line Application Engineered Product Model AC566 Product Name 2-Way Full-Range Loudspeaker System with 1 x 15" LF Product Series AE Product Type Speaker Weight 43.60lb
Crossover Type 2-way Impedance 8 ohms Sensitivity 98dB Speaker Size 15"
Maximum Frequency Response 18 kHz Minimum Frequency Response 75Hz RMS Output Power 250W
Application/Usage Bar, Club, Educational Facility, Hospitality, House of Worship, Multi Media Space, Performing Arts Center, Presentation Room, Retail Color White Depth 17.5" Form Factor Wall Mount Height 26.7" Size 15" Width 16.5"
Mount Type Wall Mount
Country of Origin CN Features 384 mm (15 in) LF transducer, 60 deg x 60 deg Waveguide with a 25 mm (1 in) exit 35mm (1.5") diaphragm compression driver, Dual Neutrik NL4 connectors plus screw terminals, Multiple Attachment Points for Ultimate Flexibility, Robust 15mm enclosure with black textured finish
