JBL Professional PD6322/43-WH Dual 12" Three-Way Full-Range Loudspeaker, White
PD6322/43|JF-PD632243W
JBL Professional PD6322/43-WH Dual 12" Three-Way Full-Range Loudspeaker, White
PD6322/43|JF-PD632243W
JBL Professional
JBL Professional PD6322/43-WH Dual 12" Three-Way Full-Range Loudspeaker, White
PD6322/43 | JF-PD632243W
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Applications:
- Performing arts facilities
- Live theaters
- Auditoriums
- Houses of worship
- Dance clubs
- Sports facilities
The low frequency section, two 2206H 300 mm (12 in) VGC™ Vented Gap Cooled low frequency transducers, offers high power handling and low power compression for high continuous SPL capability. A newly designed LF loading plate provides the highest possible sensitivity, low frequency output and system reliability.
The mid and high frequency sections are horn-loaded for maximum sensitivity and pattern control. The CMCD-82H cone midrange compression driver consists of a driver/phasing plug assembly providing high output with low distortion. The design's extended response coupled with a small 100 mm (4 in) exit diameter allow for smoother transition to the high frequency driver in the magnitude and polar pattern domains. The integral 200 mm (8 inch) transducer features a high power Differential Drive® dual voicecoil design. The 2432 H large format high frequency compression driver utilizes a neodymium magnet and aluminum diaphragm to deliver clear and intelligible high frequency projection, extended frequency response, and low distortion at even the highest drive levels.
Main Features
- 3-way loudspeaker with 1200W power
- Precision Directivity 40° by 30° coverage
- Low frequency extension to 40 Hz
- High power handling with low compression
- Horn-loaded mid and high frequency sections
- CMCD-82H cone midrange compression driver
- 2432 H high frequency compression driver
- Neodymium magnet for clear projection
- Suitable for demanding music or speech applications
- White finish for aesthetic appeal
General Information
Name: JBL Professional PD6322/43-WH Dual 12" Three-Way Full-Range Loudspeaker, White
Category: JBL Professional, Pro AV, Commercial Audio, Pro Speakers, Pro Subwoofers
UPC Code:
Country of Origin: Mexico. Country of origin is subject to change.
Specifications
ADI Part Number JF-PD632243W Brand Name JBL Professional Manufacturer Harman International Industries, Inc Manufacturer Part Number PD6322/43-WH Product Model PD6322/43 Product Name PD6322/43 High Output Three-Way Full-Range Loudspeaker with 2 x 12" LF Product Series PD Product Type Speaker Weight 192.46lb
Crossover Type 3-way Impedance 8 ohms Sensitivity 116dB Speaker Size 12"
Maximum Frequency Response 16 kHz Minimum Frequency Response 49Hz RMS Output Power 1200W
Application/Usage Auditorium, Club, House of Worship, Performing Arts Center, Sport Center, Theatre Color White Depth 35.3" Durability Weather Resistant Height 39" Material Aluminum Size 12" Width 26.5"
Limited Warranty 2-Year, 5-Year
Country of Origin MX Features Two high power 300 mm (12 in) transducers in a compact slot-loaded configuration for low frequency extension to 40 Hz. Indoor/Outdoor Outdoor
