Kramer 95-0210025 C-D9F/OPEN-25 RS-232 D9 Female to Bare End Cable, 25'
C-D9F/OPEN-25|KR-CD9FOPEN2
Kramer 95-0210025 C-D9F/OPEN-25 RS-232 D9 Female to Bare End Cable, 25'
C-D9F/OPEN-25|KR-CD9FOPEN2
Kramer Electronics
Kramer 95-0210025 C-D9F/OPEN-25 RS-232 D9 Female to Bare End Cable, 25'
C-D9F/OPEN-25 | KR-CD9FOPEN2
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Kramer's C-D9F/OPEN control cables are for RS-232 applications to control devices within a professional AV system. Many Kramer products are RS-232 controllable and equipped with terminal block connector. This RS-232 cable helps to connect them safely to transmit the RS-232 serial commands to a touch-screen system, PC, or other serial controller equipped with D9 connector.
- Quality Construction - Constructed using three 28AWG isolated conductors, terminated with a molded female 9-pin D-sub connector, nickel plated on one side and open end, non-terminated, on the second side.
- Pinout - Wired pin to pin on pins 2, 3 & 5.
- Molded Strain Relief.
- Stripped & Tinned Wires - At open end.
- RoHS Compliant.
- Varied Selection of Lengths - 3 to 50ft (1 to 15m).
Main Features
- For exceptional quality, upright compatibility and reliability use this data transfer cable
- Features Bare Wire/Serial cable type for your convenience and desired usability
- Molded feature for better usability and increased efficiency
- PC device supported according to your requirements with maximum productivity
- Control the compatible device with ease
- Fully compatible with touchscreen monitors
General Information
Name: Kramer 95-0210025 C-D9F/OPEN-25 RS-232 D9 Female to Bare End Cable, 25'
Category: Kramer Electronics, Pro AV, Commercial Connector Cables, Pro DisplayPort Cables
UPC Code: 7291063079871
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number KR-CD9FOPEN2 Brand Name Kramer Electronics Manufacturer Kramer Electronics LTD Manufacturer Part Number 95-0210025 Product Model C-D9F/OPEN-25 Product Name RS-232, D9(F) to Bare End Cable Product Type Control Cable
American Wire Gauge 24AWG Cable Type Bare Wire, Serial Connector on First End DB9 Female Connector on Second End Bare Wire Device Supported PC, Serial Controller, Touchscreen Monitor
Cable Length 25' Color Black, Red, White Material Nickel Plated, Tinned Copper
Country of Origin CN Environmental Certification RoHS Environmentally Friendly Yes Features Molded, Strain Relief
