Kramer 50-80399190 TP-780TXR 4K UHD HDMI Audio Transmitter Bi-Directional with RS-232 Ethernet and IR
TP-780Txr|KR-TP780TXR
Kramer 50-80399190 TP-780TXR 4K UHD HDMI Audio Transmitter Bi-Directional with RS-232 Ethernet and IR
TP-780Txr|KR-TP780TXR
Kramer Electronics
Kramer 50-80399190 TP-780TXR 4K UHD HDMI Audio Transmitter Bi-Directional with RS-232 Ethernet and IR
TP-780Txr | KR-TP780TXR
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
TP-780Txr is a high-performance, extended-reach HDBaseT transmitter for 4K60Hz (4:2:0) HDMI, Ethernet, RS-232 and IR signals over twisted pair. The TP-780Txr converts all input signals into the transmitted HDBaseT signal. It extends video signals to up to 100m (330') over CAT copper cables at up to 4K at 60Hz (4:2:0) 24bpp video resolution and provides even further reach for lower HD video resolutions.
Main Features
- High Performance Standard Extender
- HDMI Signal Extension
- Intelligent EDID handling, processing and pass–through algorithm that ensures Plug and Play operation for HDMI source and display systems
- Up to 32 channels of digital stereo uncompressed signals for supporting studio-grade surround sound
- Ethernet interface data flows in both directions, allowing extension of up to 100Mbps Ethernet connectivity for LAN communication and device control
- Serial interface data flows in both directions, allowing data transmission and device control
- IR interface data flows in both directions, allowing remote control of peripheral devices located at either end of the extended line
- Status LED indicators for HDMI and HDBT ports facilitate easy local maintenance and troubleshooting
- Single cable connectivity for both HDBaseT signals and power
General Information
Name: Kramer 50-80399190 TP-780TXR 4K UHD HDMI Audio Transmitter Bi-Directional with RS-232 Ethernet and IR
Category: Kramer Electronics, Residential AV, Pro AV, Residential Video Signal Distribution, Commercial Video Signal Distribution, Commercial Audio, HDMI Extenders, Pro HDMI Extenders, Pro Accessories & Mounts
UPC Code: 7291063077105
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number KR-TP780TXR Brand Name Kramer Electronics Manufacturer Kramer Electronics LTD Manufacturer Part Number 50-80399190 Product Line MegaTOOLS Product Model TP-780TXR Product Name MegaTOOLS TP-780TXR Video Extender Transmitter Product Type Video Extender Transmitter
Maximum Operating Distance 330' Media Type Supported Twisted Pair Number of Input Devices Supported 1
Maximum Video Resolution 4096 x 2160
Network (RJ-45) Yes Number of HDMI Inputs 1 Number of Network (RJ-45) Ports 2
Color Black Depth 4.53" Form Factor Rack Mount Height 1" Width 7.38"
Graphics Modes 4K
