Ubiquiti US-8-60W 8-Port Managed Switch PoE+, 60W
US-8-60W | KX-US860W
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Switch from Ubiquiti Networks features 8 Gigabit Ethernet ports in a small form factor offering improved performance and intelligent switching capabilities for expanding networks. In addition to the 8 Gigabit Ethernet ports, this switch offers 8 Gbps non-blocking throughput, a 16 Gbps switching capacity, and a 11.9 mpps forwarding rate. It also delivers up to 15.4W of power per PoE port. Once installed, this UniFi switch can be managed using Ubiquiti's own UniFi Controller software giving network administrators the ability to manage multiple sites from a single interface. Network admins have full access to various Ubiquiti devices within the network with the ability to change operating modes, monitor the status of each device, manage spanning tree configuration, and much more.
Main Features
- Non-Blocking Throughput Switching Performance
- Gigabit Ethernet RJ45 Ports
- Robust Performance for Enterprise Networks
- Fanless, silent cooling
General Information
Name: Ubiquiti US-8-60W 8-Port Managed Switch PoE+, 60W
Category: Ubiquiti, Data Comm & Networking, Hubs, Routers & Switches, Network Switches
UPC Code: 810354026164
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number KX-US860W Brand Name Ubiquiti Manufacturer Ubiquiti Inc. Manufacturer Part Number US-8-60W Product Line UniFi Product Model US-8-60W Product Name Ubiquiti Networks US-8-60W UniFi 8-Port Gigabit PoE Compliant Managed Switch Product Series US Product Type Network Switch Weight 15.2oz
Media Type Supported Twisted Pair Power Consumption 12W
Network Switch Type Managed, Poe
Modular No Network (RJ-45) Yes Total Number of Network Ports 8 Uplink Port No
Manageable Yes
Network Technology 10/100/1000Base-T
Ethernet Technology 10 Gigabit Ethernet Layer Supported 2
Depth 3.9" Height 1.2" Material SGCC Steel Width 5.8"
Frequency 50 Hz|60 Hz Input Voltage 100-240V AC Power Source DC
Limited Warranty 1-Year
Country of Origin CN Features 16 Gbps Switching Capacity, 4 x Auto-Sensing 802.3af PoE Ports, 8 Gbps Non-Block Throughput, Fanless, silent cooling Package Contents - UniFi US-8-60W Ethernet Switch
- AC Adapter
