Ubiquiti USW-PRO-24-POE 24-Port Pro 24 PoE Layer 3 Switch with PoE++ Output, Silver
USW-PRO-24-POE|KX-USWPRO24P
Ubiquiti USW-PRO-24-POE 24-Port Pro 24 PoE Layer 3 Switch with PoE++ Output, Silver
USW-PRO-24-POE|KX-USWPRO24P
Ubiquiti
Ubiquiti USW-PRO-24-POE 24-Port Pro 24 PoE Layer 3 Switch with PoE++ Output, Silver
USW-PRO-24-POE | KX-USWPRO24P
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Expand your business's network with the fully manageable second-generation UniFi Pro PoE 24-Port Gigabit Managed PoE Network Switch with SFP+ from Ubiquiti. Designed with Layer 3 protocol support, the passively cooled 24-port Gigabit switch features a total power budget of 400W across 16 32W PoE connectors and eight 64W PoE++ ports for power-intensive devices such as high-resolution network security cameras. Each port delivers 44 Gb/s non-blocking throughput with a 88 Gb/s switching capacity and a 65.47 Mpps forwarding rate. Two 10 Gb/s SFP+ ports are available for additional network expansion using compatible devices. Administrators may monitor and manage the switch with the 1.3" touchscreen display or access and configure it and connected devices using the UniFi Network Controller application.
Main Features
- Auto-Sensing IEEE 802.3af/at/bt PoE
- SFP+ Ports for 10G Links
- Integrated Fans for Near-Silent Cooling
- 16 x PoE+ Ports and 8 x PoE++ Ports
- 2 x 10 Gb/s SFP+ Ports
- The UniFi Pro PoE Switch supports has an external DC power interface, which works with a separate power adapter as a power backup if the internal PSU fails
- You may use a single instance of the UniFi Controller running in the cloud from a centralized interface to manage multiple UniFi sites. Each site is logically separated with its own network monitoring, configuration, maps, statistics, and administrator accounts.
General Information
Name: Ubiquiti USW-PRO-24-POE 24-Port Pro 24 PoE Layer 3 Switch with PoE++ Output, Silver
Category: Ubiquiti, Data Comm & Networking, Hubs, Routers & Switches, Network Switches
UPC Code: 817882028349
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number KX-USWPRO24P Brand Name Ubiquiti Manufacturer Ubiquiti Inc. Manufacturer Part Number USW-PRO-24-POE Product Line UniFi Product Model USW-PRO-24-POE Product Name Ubiquiti Networks UniFi Pro PoE 24-Port Gigabit Managed PoE Network Switch with SFP+ Product Series USW Pro Product Type Network Switch Weight 9.7lb
Material SGCC Steel Media Type Supported Optical Fiber, Twisted Pair Power Consumption 50W
Expansion Slot Type SFP+ Number of SFP+ Slots 2 Number of Total Expansion Slots 2
Modular Yes Network (RJ-45) Yes Total Number of Network Ports 24 Uplink Port Yes
Manageable Yes
Network Technology 10/100/1000Base-T, 10GBase-X
Ethernet Technology 10 Gigabit Ethernet Layer Supported 3
Compatible Rack Unit 1U Depth 11.2" Height 1.7" Width 17.4"
Frequency 50 Hz|60 Hz Input Voltage 100-240V AC PoE Budget 400W Power Source AC, DC
Limited Warranty 1-Year
Environmentally Friendly Yes Features 16 x PoE+ Ports and 8 x PoE++ Ports, 2 x 10 Gb/s SFP+ Ports, 24 x Gigabit Ethernet Ports, 88 Gb/s Switching Capacity, Near-silent cooling, The UniFi Pro PoE Switch supports has an external DC power interface, which works with a separate power adapter as a power backup if the internal PSU fails Package Contents - USW-Pro-24-POE Layer 3 Switch
- Rack Mount Hardware
