Ubiquiti USW-PRO-48-POE 48-Port Pro 48 PoE Layer 3 Switch with PoE++ Output, Silver
USW-PRO-48-POE|KX-USWPRO48P
Ubiquiti USW-PRO-48-POE 48-Port Pro 48 PoE Layer 3 Switch with PoE++ Output, Silver
USW-PRO-48-POE|KX-USWPRO48P
Ubiquiti
Ubiquiti USW-PRO-48-POE 48-Port Pro 48 PoE Layer 3 Switch with PoE++ Output, Silver
USW-PRO-48-POE | KX-USWPRO48P
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Expand your business's network with the fully manageable second-generation UniFi Pro PoE 48-Port Gigabit Managed PoE Network Switch with SFP+ from Ubiquiti. Designed with Layer 3 protocol support, the passively cooled 48-port Gigabit switch features a total power budget of 600W across 40 32W PoE connectors and eight 64W PoE++ ports for power-intensive devices such as high-resolution network security cameras. Each port delivers 88 Gb/s non-blocking throughput with a 176 Gb/s switching capacity and a 130.94 Mpps forwarding rate. Four 10 Gb/s SFP+ ports are available for additional network expansion using compatible devices. Administrators may monitor and manage the switch with the 1.3" touchscreen display or access and configure it and connected devices using the UniFi Network Controller application.
Main Features
- (40) GbE PoE+, (8) GbE PoE++ ports
- (4) 10G SFP+ ports
- 600W total PoE availability
- DC Power backup ready
- Layer 3 switching
- Near-silent cooling
- The UniFi Pro PoE Switch supports has an external DC power interface, which works with a separate power adapter as a power backup if the internal PSU fails
General Information
Name: Ubiquiti USW-PRO-48-POE 48-Port Pro 48 PoE Layer 3 Switch with PoE++ Output, Silver
Category: Ubiquiti, Data Comm & Networking, Hubs, Routers & Switches, Network Switches
UPC Code: 817882028356
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number KX-USWPRO48P Brand Name Ubiquiti Manufacturer Ubiquiti Inc. Manufacturer Part Number USW-PRO-48-POE Product Line UniFi Product Model USW-PRO-48-POE Product Name Ubiquiti Networks UniFi Pro PoE 48-Port Gigabit Managed PoE Network Switch with SFP Product Series USW Pro Product Type Network Switch Weight 14lb
Material SGCC Steel Media Type Supported Optical Fiber, Twisted Pair Power Consumption 60W
Expansion Slot Type SFP+ Number of SFP+ Slots 4 Number of Total Expansion Slots 4
Modular Yes Network (RJ-45) Yes Total Number of Network Ports 48 Uplink Port Yes
Manageable Yes
Network Technology 10/100/1000Base-T, 10GBase-X
Ethernet Technology 10 Gigabit Ethernet Layer Supported 3 Networking Standards IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Compatible Rack Unit 1U Depth 15.7" Height 1.7" Width 17.4"
Frequency 50 Hz|60 Hz Input Voltage 100-240V AC PoE (RJ-45) Port Yes PoE Budget 600W Power Source AC, DC
Limited Warranty 1-Year
Environmentally Friendly Yes Features 176 Gb/s Switching Capacity, 4 x 10 Gb/s SFP+ Ports, 40 x PoE+ Ports and 8 x PoE++ Ports, 48 x Gigabit Ethernet Ports, Near-silent cooling, The second-generation UniFi switch offers a 130.94 Mpps forwarding capacity to simultaneously process traffic on all ports without packet loss. The UniFi PoE Pro Switch has a non-blocking throughput of 88 Gb/s with a 176 Gb/s switching capacity., The UniFi Pro PoE Switch supports has an external DC power interface, which works with a separate power adapter as a power backup if the internal PSU fails Package Contents - USW-Pro-48-PoE Layer 3 Switch
- Rack Mount Hardware
