Leviton 1N240-2D S1K 2-Pole 3-Wire 2000.1A DMD IM Smart Dimmer and Light Switch
1N240-2D|LV-1N2402D
Leviton 1N240-2D S1K 2-Pole 3-Wire 2000.1A DMD IM Smart Dimmer and Light Switch
1N240-2D|LV-1N2402D
Leviton
Leviton 1N240-2D S1K 2-Pole 3-Wire 2000.1A DMD IM Smart Dimmer and Light Switch
1N240-2D | LV-1N2402D
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Series 1000 Submeter, Dual Element Demand Meter, 1P/3W, 120/208/240V, 200:0.1A, Max 200A, Submeter Only. The Leviton VerifEye Series 1000 line of revenue-grade submeters meets all measurement and verification-based opportunities - including load management and LEED rating achievement. Designed to provide a simple and effective process for accurately capturing measurements of power consumption, Series 1000 submeters are easy to specify and install for new construction and retrofits.
Main Features
- Measures kWh and demand (optional)
- Conforms to all applicable standards of ANSI C12.1
- Equipped with an Isolated Pulse Output channel
- Utilizes revenue-grade 0.3% accuracy class 0.1A secondary solid core CTs that conform to all applicable ANSI requirements or 1.0% accuracy split-core CTs
- Up to three sets of CTs per phase can be paralleled per meter without the need for a meter multiplier
- Enclosures include surface mount industrial grade JIC steel indoor and NEMA 4X outdoor
- Interfaces with numerous communication systems; Hardwired Automatic Meter Reading (AMR) or wireless AMR
- Large LCD display shows kWh and instantaneous and peak demand (optionally) with manual keyed reset
- Load Indicator LED verifies meter functionality
- Reverse Phase Indicator LED illuminates if the meter is improperly installed
General Information
Name: Leviton 1N240-2D S1K 2-Pole 3-Wire 2000.1A DMD IM Smart Dimmer and Light Switch
Category: Leviton, Smart Home, Smart Dimmers & Light Switches
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number LV-1N2402D Brand Name Leviton Manufacturer Part Number 1N240-2D Product Line Series 1000 Product Name Submeter, Indoor, 120/208/240V, 1 Phase 3 Wire, Max 200A, Dual Element, Demand, Electric Meter Product Series Series 1000 Product Type Electric Meter
Application/Usage Cost reduction, Electric/electrical/electricity submetering, Energy conservation, Government mandates, Green building initiatives, LEED achievement, Load profiling and benchmarking, Measurement and verification, Tenant cost allocation, Usage aggregation
Input Voltage 120V, 208V, 240V AC
Limited Warranty 5-Year
Country of Origin US Environmental Certification NEMA 1, UL
