Leviton 3OUMT-2SM 3300 Series Electric Meter Kit, Submeter, Outdoor, 208-480VAC, 3-Phase 3-4 Wire, Max 200A, 3 Solid Core Current Transformers
Leviton 3OUMT-2SM 3300 Series Electric Meter Kit, Submeter, Outdoor, 208-480VAC, 3-Phase 3-4 Wire, Max 200A, 3 Solid Core Current Transformers
Leviton 3OUMT-2SM 3300 Series Electric Meter Kit, Submeter, Outdoor, 208-480VAC, 3-Phase 3-4 Wire, Max 200A, 3 Solid Core Current Transformers
3OUMT-2SM | LV-3OUMT2SM
Please sign in to view pricing and availability and to add to cart.
Product Overview
Modbus TCP/BACnet IP - Outdoor Series 3500 Multi-Function Universal Voltage (208-480VAC) 3 PHASE 3W/4W Submeter Kit (CTs included), 200A Solid Core Current Transformers (CT) Provides highly accurate, multi-functional smart-metering solutions for seamless integration into advanced building control management systems. The Series 3300 and 3500 meters feature advanced communication protocols to enable tracking, monitoring and verification of real-time energy use and easy building management system integration. Series 3300 communicates via Modbus RTU or BACnet MS/TP over RS-485 and Ethernet enabled Series 3500 features Modbus TCP/IP and BACnet IP. Both meters deliver universal voltage performance, offer standard isolated pulse outputs, and easily integrate with building management systems.
Main Features
- Series 3500; Enabled by Ethernet, uses Modbus TCP/IP and BACnet IP
- Isolated pulse output
- Integrates easily with building management systems
- Highly accurate 0.5% accuracy class
- Delivers universal voltage performance
- 208/480V 2PH 2W, 120/208V 2PH 3W, 240/480V 3PH 3W, 120/208V, 277/480V 3PH 4W, 240/480V 3PH 4W DELTA
- 100-5000 Amps
- Outputs kWh, Demand - Instant and Peak, Per Phase and Total kWh, kW, kVAR, VAR, AMPS Interval Data
- Certified to all applicable standards of ANSI C12.1
- Utilizes split and solid core current transformers (CTs) that are certified to all revenue grade accuracy standards
General Information
Specifications
ADI Part Number LV-3OUMT2SM Brand Name Leviton Manufacturer Part Number 3OUMT-2SM Product Name Submeter, Outdoor, 208-480VAC, 3 Phase 3 Wire/4 Wire, Max 200A, 3 Solid Core Current Transformers, Electric Meter Kit Product Type Submeter and Current Transformer
