Leviton 49FR1-XE High Amp Complete Female Receptacle, Single Hole, Red
Leviton 49FR1-XE High Amp Complete Female Receptacle, Single Hole, Red
Leviton 49FR1-XE High Amp Complete Female Receptacle, Single Hole, Red
49FR1-XE | LV-49FR1XE
Please sign in to view pricing and availability and to add to cart.
Product Overview
Rhino-Hide 49 Series Single Pole Female 45 Degree Receptacle (Color Coded Metal Housing, Contact, Captive Clevis Pin & Dust Cap), Single Hole Bus Bar, Industrial Grade, 313MCM-777MCM Cable, 1000 Volt, 1135 Amp Max - BLACK
Designed for the most extreme, demanding conditions, the 49 Series of high amperage devices includes male and female plugs, panel mount receptacles and accessories. They are an ideal solution for installations on both new and existing silicon-controlled rectifiers (SCRs) and generator stations as well as on generator stations and new oil or gas rigs.
Cast aluminum powder-coated receptacle housing is color-coded for quick visual identification of circuit and phase connections
TPV cap prevents contamination when receptacle is not in use
Captive stainless steel clevis bracket accepts industry standard lockout; "X" versions feature 45° for easier access in smaller panels
Main Features
- High amp capacity: 1135 Amp Max
- Supports 1000 Volt systems
- Color-coded metal housing for easy identification
- 45° design for tight spaces
- Captive clevis pin for secure connections
- Dust cap prevents contamination
- Compatible with 313MCM-777MCM cables
- Industrial grade for extreme conditions
- Ideal for SCRs and generator stations
- Black color for circuit identification
General Information
Specifications
ADI Part Number LV-49FR1XE Brand Name Leviton Manufacturer Leviton Mfg. Company, Inc Manufacturer Part Number 49FR1-XE Product Line Rhino-Hide Product Name Female Receptacle, 313-777 MCM, Single Hole Bus Bar Product Type Power Socket
Color Black Material Powder-Coated Cast Aluminum
