MSSMT-GDT | LV-MSSMTGDT
Please sign in to view pricing and availability and to add to cart.
Product Overview
LevLok Multi-Tech wall box occupancy sensor with no neutral wire lighting control, 120/208/220/230/240/277V, 50/60 Hz, CEC Title 20/24 Compliant, 30 s-30 min Time Delays, Ambient Light Override, Self Adjusting, Field Configurable, Color- Light Almond, USMCA Compliant. Lev-Lok's innovative design streamlines installation and reduces costs. In just two easy steps, the wiring device is securely attached to the wiring module. Place the wiring module over the device's connection pins and twist clockwise to lock. Replacement is just as easy just turn counter-clockwise to unlock and remove. The module is keyed so that it cannot be installed incorrectly. This not only saves time during the initial installation, but makes maintenance applications quicker, safer and easier as well.
Main Features
- Fits in a standard wall box and replaces a single-pole wall-switch
- Low-profile design eliminates obtrusive "scanning-device" look
- Convenient Pushbutton provides manual-ON / OFF light switching at any time
- Segmented Fresnel lens provides optimum sensitivity and performance
- Vandal resistant PIR lens
- Lev-Lok makes installation and replacement simple with latch-and-lock system which streamlines installation and reduces costs
- Adjustable horizontal field-of-view
- LED Indicator light flashes when sensor detects motion to verify detection is active
General Information
Specifications
ADI Part Number LV-MSSMTGDT Brand Name Leviton Manufacturer Part Number MSSMT-GDT Product Line Lev-Lok Product Name Occupancy Sensor, Lev-Lok, Multi-Technology (PIR Sensor / Ultrasonic Sensor), Wall Switch Product Type Switch
Control Type Push Button Controllable Function Light Control
Application/Usage Classrooms, Conference Rooms, Lounges, Multi-location switching (similar to 3-way), Private and Executive Offices, Restrooms, Retrofit, Storage Areas, Training Areas Color Almond Depth 2.29" Height 4.06" Width 1.75"
Input Voltage 120V AC, 230V AC, 277V AC Maximum Frequency 50/60 Hz
Switch Type Single-Pole
Limited Warranty 5-Year
