Leviton TDR20-S1G Decora Plus Duplex Receptacle Outlet, CP0/10/050
TDR20-S1G|LV-TDR20S1G
Leviton TDR20-S1G Decora Plus Duplex Receptacle Outlet, CP0/10/050
TDR20-S1G|LV-TDR20S1G
Leviton
Leviton TDR20-S1G Decora Plus Duplex Receptacle Outlet, CP0/10/050
TDR20-S1G | LV-TDR20S1G
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Decora Plus Duplex Receptacle Outlet, Heavy-Duty Industrial Specification Grade, Split-Circuit, One Outlet Marked "Controlled" , Tamper-Resistant, Smooth Face, 20 Amp, 125 Volt, Back or Side Wire, NEMA 5-20R, 2-Pole, 3-Wire, Self-Grounding - Gray
Leviton offers custom imprinting solutions to meet the 2014 National Electrical Code requirements for identifying receptacles that will be automatically de-energized as part of an overall plug load control program. All 15A & 20A, 125V receptacles that are automatically controlled will be marked with a specific symbol.
Main Features
- Heavy-duty industrial specification grade
- Split-circuit design with one controlled outlet
- Tamper-resistant for safety
- Smooth face for a sleek appearance
- 20 Amp, 125 Volt capacity
- Back or side wire installation
- NEMA 5-20R, 2-pole, 3-wire configuration
- Self-grounding for convenience
- Custom imprinting for NEC compliance
- Gray Color for Versatile Use
General Information
Name: Leviton TDR20-S1G Decora Plus Duplex Receptacle Outlet, CP0/10/050
Category: Leviton, Data Comm & Networking, Wall Plates & Mounts, Wall Plate Inserts
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number LV-TDR20S1G Brand Name Leviton Manufacturer Leviton Mfg. Company, Inc Manufacturer Part Number TDR20S1G Product Line Decora Plus Product Name Marked "Controlled" Tamper-Resistant Duplex Receptacle Product Type Power Socket
Color Gray Material Nylon
Limited Warranty 10-Year
