Image of OG-B540EXT33
Binary

Binary B-540-EXT-330-RS-IP 540 Series 4K Ultra HD HDBaseT Long-Range Extender with IR, RS-232 and Ethernet

B-540-EXT-330-RS-IP|OG-B540EXT33
Binary

Binary B-540-EXT-330-RS-IP 540 Series 4K Ultra HD HDBaseT Long-Range Extender with IR, RS-232 and Ethernet

B-540-EXT-330-RS-IP|OG-B540EXT33

Sign In for Dealer Pricing

Become an ADI Customer
Image of OG-B540EXT33
Binary

Binary B-540-EXT-330-RS-IP 540 Series 4K Ultra HD HDBaseT Long-Range Extender with IR, RS-232 and Ethernet

B-540-EXT-330-RS-IP | OG-B540EXT33

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

Extend audio and video signals and gain control system capability over long distances without sacrificing resolution. This HDBaseT extender transmits up to 4K@60Hz video (compatible with HDMI 2.0 and HDCP 2.2), 7.1 channels of lossless audio, and Ethernet – all up to 330' over a single Cat 5e/6 cable. Bi-directional Power over Cable (POC) eliminates the need to fit a bulky power supply behind the TV, saving valuable install time, while “plug and play” technology bypasses frustrating EQ and EDID settings. Support for 100Mb Ethernet makes streaming Netflix or Pandora on your Smart TVs easier than ever. Plus, you get robust control system integration that includes not only Ethernet, but bi-directional IR and RS-232 as well. This extender supports 4K@30 Hz (4:4:4) and 4K@60 Hz (4:2:0) resolutions.

2-Year Limited Warranty: This Binary product has a 2-year limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty will not apply to products that have been abused, modified or disassembled. Products to be repaired under this warranty must be returned to Snap One or a designated service center with prior notification and an assigned return authorization number (RA).

Main Features

  • 4K Ultra HD video transmission up to 330'
  • Supports HDMI 2.0 and HDCP 2.2
  • Bi-directional Power over Cable (POC)
  • Plug and play technology for easy setup
  • Supports 7.1 channels of lossless audio
  • Includes Ethernet, IR, and RS-232 control
  • Compatible with Cat 5e/6 cables
  • Supports 4K@30 Hz (4:4:4) and 4K@60 Hz (4:2:0)
  • 2-year limited warranty included

General Information

Name: Binary B-540-EXT-330-RS-IP 540 Series 4K Ultra HD HDBaseT Long-Range Extender with IR, RS-232 and Ethernet
Category: Residential AV, Pro AV, Residential Video Signal Distribution, Commercial Video Signal Distribution, HDMI Extenders, Pro HDMI Extenders
UPC Code: 842822034067
Country of Origin: TW. Country of origin is subject to change.

Specifications

Product Documents and Resources
