Lantronix C6310-3340 ION POTS Media Converter, Twisted Pair RJ-11 Port and Fiber Port
Lantronix C6310-3340 ION POTS Media Converter, Twisted Pair RJ-11 Port and Fiber Port
Lantronix C6310-3340 ION POTS Media Converter, Twisted Pair RJ-11 Port and Fiber Port
C6310-3340 | P6-C63103340
Please sign in to view pricing and availability and to add to cart.
Product Overview
The ION C6310-3340 is a chassis-based media converter module that provides an interface between a twisted pair RJ-11 port and a fiber port, allowing users to connect central-office voice grade signals to distant Plain Old Telephone equipment (POTS) utilizing standard telephone signaling. Two units are required to implement an end to end system. The first unit connects to a telephone line or PBX and is configured to act as a telephone (FXO Mode) and has the ability to detect ringing voltages. The second unit is the reciprocal unit and is configured to have the ability to act as a Central Office and connects to a telephone device (FXS Mode).
Together, the modules allow legacy analog phone lines to be extended over fiber for both permanent installations as well as temporary job-site installations.
Main Features
- Audio transmission of voice grade signals
- Supports ringing at distant end
- Supports Caller ID
- Configurable worldwide country formats
- Must be deployed in pairs:ION chassis card and stand-alone unit - ION chassis card and ION chassis card - Stand-alone unit and stand-alone unit
- Single product configurable to either FXO mode or FXS mode
- Automatic Ring Down supported when both converters are configured to FXS Mode
- SFP based product: Uses Gigabit Ethernet SFP Modules - Lantronix offers a wide variety of SFP modules to support multimode or singlemode fiber, as well as dual or single strand fiber installations
- SNMP Management supported when installed in a managed ION chassis
- Supports remote management of paired unit, in-band, over the fiber
General Information
Specifications
ADI Part Number P6-C63103340 Brand Name Lantronix Manufacturer Lantronix, Inc Manufacturer Part Number C63103340 Maximum Distance 3.11 Mile Product Line ION Product Model C6310-3340 Product Name C6310-3340 ION POTS Media Converter Product Type Transceiver/Media Converter Weight 1lb
Fiber Optic Mode Multimode, Single-mode Media Type Supported Optical Fiber, Twisted Pair Power Consumption 2W
Expansion Slot Type SFP Number of SFP Slots 1 Number of SFP+ Slots 1 Number of Total Expansion Slots 1
Ethernet Technology Gigabit Ethernet
Depth 6.5" Height 3.4" Width 0.9"
Power Source DC
Limited Warranty Lifetime
Environmental Certification CE, FCC TAA Compliant Yes
