Lantronix S3290-42-SA NID 4XTP 2XSFP SA Bundle
Lantronix S3290-42-SA NID 4XTP 2XSFP SA Bundle
Lantronix S3290-42-SA NID 4XTP 2XSFP SA Bundle
S3290-42 | P6-S329042SA
Please sign in to view pricing and availability and to add to cart.
Product Overview
Remotely Managed NID with Built-in Traffic Generator
Lantronix managed S3290 NID provides advanced packet performance metering and service creation directly at the customer premises and cell sites. The S3290 is optimized for business Ethernet and mobile backhaul deployments.
The S3290 is a multi-service NID that provides SLA-assurance and advanced fault management that is MEF CE 2.0 certified. The S3290 supports advanced features and numerous security features. The S3290 can be managed and provisioned with Lantronix's CommandPoint NMS or via Web, CLI and SNMP (v1, v2c & v3). The S3290 offers AC or DC power inputs for operation in a variety of environments. The SFP ports support 100Mbps, 1000Mbps or SGMII SFPs. CWDM and Bi-Di SFPs are also supported, allowing for flexible network architectures.
Main Features
- Any port can be network (NNI) or client (UNI)
- MPLS-TP
- SNMP v1, v2c, and v3
- IPv6 and IPv4 support
- VLAN (IEEE 802.1Q) in-Q (C-Tag / S-Tag)
- RMON and SYSLOG
- OAM Support: IEEE 802.3ah Link OAM | IEEE 802.1ag Service OAM | ITU Y.1731 Performance Monitoring
- Protection: ITU G.8032/G.8031 | IEEE RSTP, MSTP
- IEEE 1588v2
- DC or AC power input
General Information
Specifications
ADI Part Number P6-S329042SA Brand Name Lantronix Manufacturer Lantronix, Inc Manufacturer Part Number S329042SA Packaged Quantity 2 Product Model S3290-42 Product Name S3290-42 Transceiver/Media Converter Product Series S3290 Product Type Transceiver/Media Converter
Media Type Supported Optical Fiber, Twisted Pair
Expansion Slot Type SFP Number of SFP Slots 2 Number of SFP+ Slots 2 Number of Total Expansion Slots 2
Network (RJ-45) Yes
Network Technology 10/100/1000Base-T, 100/1000Base-X
Ethernet Technology Gigabit Ethernet
Depth 6.5" Form Factor DIN Rail Mount, Rack Mount, Shelf Mount, Wall Mount Height 1" Width 6"
Input Voltage 12V DC Power Source Power Supply
Limited Warranty 5-Year
Environmental Certification REACH, RoHS, WEEE Environmentally Friendly Yes Package Contents S3290-42 Transceiver/Media ConverterPower Supply - South Africa
