QSC AD-DWL.SUB AcousticDesign Series Dual 5.25" Subwoofer Outdoor Landscape Loudspeaker
AD-DWL.SUB|QB-ADDWLSUB
QSC AD-DWL.SUB AcousticDesign Series Dual 5.25" Subwoofer Outdoor Landscape Loudspeaker
AD-DWL.SUB|QB-ADDWLSUB
QSC
QSC AD-DWL.SUB AcousticDesign Series Dual 5.25" Subwoofer Outdoor Landscape Loudspeaker
AD-DWL.SUB | QB-ADDWLSUB
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The QSC AcousticDesign Series AD-DWL loudspeakers have been weatherized offering a superior and ruggedized to face the elements while offering a superior customized sound experience for your outdoor installation and providing a lasting return on investment.
Main Features
- Elevated bollard design allows sound to travel above obstructions
- Permanent direct-to-concrete or in-earth base supports resist tampering
- Green enclosures (RAL 6020) allow for unobtrusive aesthetic (or take advantage of paintable exterior finish)
- Durable polypropylene/fiberglass construction and stainless-steel hardware; no fragile paper cone components
- IP55 (Ingress Protection rating) and UL 1480 Compliant
- Intrinsic Correction advanced QSC voicing filter sets available via Q-SYS or CXD DSP amplifier platforms
- Designed for a wide range of environmental conditions from -5 - 50C (20 - 125F), high humidity, and salt mist conditions
General Information
Name: QSC AD-DWL.SUB AcousticDesign Series Dual 5.25" Subwoofer Outdoor Landscape Loudspeaker
Category: QSC, Pro AV, Commercial Audio, Pro Subwoofers
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number QB-ADDWLSUB Brand Name QSC Manufacturer QSC Audio Manufacturer Part Number AD-DWL.SUB Packaged Quantity 1 Product Line AcousticDesign Product Model AD-DWL.SUB Product Name AD-DWL.SUB Dual 5.25-Inch Landscape Subwoofer Product Series AcousticDesign Product Type Landscape Speakers Weight 10.36lb
Crossover Type 2-way Impedance 16 ohms Material Cone Sensitivity 84dB Speaker Size 5.25"
Maximum Frequency Response 200 Hz Minimum Frequency Response 48Hz Number of Speakers 1 RMS Output Power 160W Subwoofer Type Passive
Application/Usage Landscape Color Green Depth 6.46" Durability Humidity Resistant, Salt Resistant, Sprayproof, Tamper Resistant, Temperature Resistant, UV Resistant, Weather Resistant Enclosure Type Sealed Form Factor Direct Mount Height 30.16" Size 5.31" Width 6.46"
Mount Type Direct Mount
Limited Warranty 3-Year
Environmental Certification RoHS Environmentally Friendly Yes Features Rugged Design Indoor/Outdoor Outdoor Package Contents - AD-DWL.SUB Dual 5.25-Inch Landscape Subwoofer
- 1 x Collar
- 1 x Quick Start Guide
- 1 x Installation Template
- 1 x Paint Mask
- 4 x Collar Torx Screws
- 1 x Torx Bit
