Hanwha PNM-9000QB P-Series 2MP 4-Channel Remote Head Camera Main Module, White
PNM-9000QB|SQ-PNM9000QB
Hanwha PNM-9000QB P-Series 2MP 4-Channel Remote Head Camera Main Module, White
PNM-9000QB|SQ-PNM9000QB
Hanwha Vision
Hanwha PNM-9000QB P-Series 2MP 4-Channel Remote Head Camera Main Module, White
PNM-9000QB | SQ-PNM9000QB
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The PNM-9000QB Wisenet P series, powered by the Wisenet 7 SoC, supports 4x2MP lenses. Covert camera main module, full HD (1080p) 30fps, H.265/H.264/MJPEG, WiseStream II compression technology, 120dB extremeWDR, dual micro SD/SDHC/SDXC card slots, bi-directional audio, USB port for easy installation, advanced video analytics and sound detection.
Main Features
- 2MP (1920x1080) Resolution
- H.265, H.264 and MJPEG codec support, Multiple streaming
- 30 fps, 2MP (H.265/H.264)
- HDMI Monitor output for single/quad view
- Extreme WDR (120dB), Defog, DIS
- Tampering, loitering, directional detection, fog detection and audio detection
- Motion detection
- MicroSDXC Memory slot (Maximum 2x256GB), Hallway View, WiseStream II
- LDC, PoE / 12V DC, Bi-directional audio support
General Information
Name: Hanwha PNM-9000QB P-Series 2MP 4-Channel Remote Head Camera Main Module, White
Category: Hanwha Vision, Video Surveillance, Video Accessories, Transmitters & Extenders, ADI Pro Rewards
UPC Code: 8801089192301
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number SQ-PNM9000QB Brand Name Hanwha Vision Manufacturer Hanwha Vision Manufacturer Part Number PNM-9000QB NDAA Compliant Yes Product Model PNM-9000QB Product Name 2MP x 4 Remote Head Camera Product Series P Product Type Camera Weight 1.58lb
Connectivity Technology Wired Effective Camera Resolution 2MP Maximum Frame Rate 30fps Video Formats H.264, H.265, MJPEG
Wide Dynamic Range Yes
Maximum Video Resolution 1920 x 1080
Maximum Operating Temperature 113°F Minimum Operating Temperature -40°F Operating Humidity 0-95% RH (Non-condensing)
Longest Shutter Speed 2 Second Shortest Shutter Speed 1/12,000 Second
HDMI Yes Network (RJ-45) Yes
Lens Included No
Remote Management Yes
Color White Depth 5.75" Form Factor Remote Head Height 1.46" Width 7.87"
Input Voltage 12V DC
Mount Type Desktop Mount, Rack Mount, Wall Mount
Recording Formats Full HD Storage Type Memory Card
Features 2 MP (1920 x 1080) resolution, 30fps at 2MP (H.265/H.264), ExtremeWDR (120dB), Defog, DIS, H.265, H.264, MJPEG codec support, Multiple streaming, HDMI Monitor output for single/quad view, LDC, PoE/12V DC, Bi-directional audio support, MicroSDXC Memory slot 1TB (512GBx2), Motion Detection, Tampering, Loitering, Directional detection, Fog detection, Audio detection, WiseStream II
