Hanwha XNO-8020R X-Series 5MP IR Bullet Camera, 3.7mm Fixed Lens, Gray
XNO-8020R|SQ-XNO8020R
Hanwha XNO-8020R X-Series 5MP IR Bullet Camera, 3.7mm Fixed Lens, Gray
XNO-8020R|SQ-XNO8020R
Hanwha Vision
Hanwha XNO-8020R X-Series 5MP IR Bullet Camera, 3.7mm Fixed Lens, Gray
XNO-8020R | SQ-XNO8020R
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
WiseNet X powered by WiseNet 5 network outdoor vandal bullet camera, Back box, 5MP @30fps WDR off/on, 3.7mm fixed lens (97.5°), H.265/H.264/MJPEG, WiseStream II compression technology, 120dB WDR, USB port for easy installation, advanced video analytics and sound classification, High powered IR LEDs range of 98', True D/N, dual SD card, hallway view, HLC, defog detection with simple focus, DIS , 12VDC/24VAC/PoE, IP67, IK10, Nema 4X
Main Features
- Built-in 3.7 mm fixed lens
- Max. 30 fpsatall resolutions (H.265/H.264)
- Loitering, Directional detection, Fog detection, Audio detection, Digital auto tracking, Sound classification, Heatmap, People counting, Queue management, Tampering
- Motion detection, Handover
- Dual SD slots (Max. 512GB),WiseStream II support
- IR viewable length 30m, IP67/IP66, NEMA 4X, IK10
General Information
Name: Hanwha XNO-8020R X-Series 5MP IR Bullet Camera, 3.7mm Fixed Lens, Gray
Category: Hanwha Vision, Video Surveillance, IP Cameras, Bullet Cameras, ADI Pro Rewards
UPC Code: 8801089100658
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number SQ-XNO8020R Brand Name Hanwha Vision Manufacturer Hanwha Vision Manufacturer Part Number XNO-8020R Product Model XNO-8020R Product Name 5MP IR Bullet Product Series X Product Type Bullet Camera Weight 2.87 lb
Effective Camera Resolution 5MP Field of View H: 97.5°, V: 71.9°, D: 126.2° Lens Type Fixed Maximum Aperture f/1.6 Maximum Frame Rate 30fps Minimum Focal Length 3.7mm Night Vision Yes Night Vision Type Infrared Video Formats H.264, H.265, MJPEG, MPEG-4
Connectivity Technology Wired Image Sensor Type CMOS Night Vision Distance 98 ft Wide Dynamic Range Yes
Maximum Video Resolution 3096 x 2094
Maximum Operating Temperature 131°F Minimum Operating Temperature -22°F Operating Humidity 90% RH
Longest Shutter Speed 2 Second Minimum Illumination 0.2 lux Shortest Shutter Speed 1/12000 Second
Network (RJ-45) Yes
Focal Length 3.7 mm Lens Included Yes Maximum Focal Length 3.70 mm
Remote Management Yes
Color Gray Durability Dustproof, Impact Resistant, Vandal Resistant, Waterproof Form Factor Bullet Height 11.65"
Input Voltage 12V DC
Diameter 4.72" Length 11.7" Mount Type Board-in Type
Recording Formats HD Storage Type Memory Card
Limited Warranty 3-Year
Features Back Light Compensation (BLC), Built-in IR LED, Day/Night, Highlight Compensation (HLC), SD Card Local Storage Impact Protection Rating IK10 Indoor/Outdoor Outdoor
