Hanwha XRN-420S X-Series 8MP 4-Channel NVR with PoE Switch, 50Mbps, HDD Not Included (Replaces XRN-410S)
XRN-420S|SQ-XRN420S
Hanwha XRN-420S X-Series 8MP 4-Channel NVR with PoE Switch, 50Mbps, HDD Not Included (Replaces XRN-410S)
XRN-420S|SQ-XRN420S
Hanwha Vision
Hanwha XRN-420S X-Series 8MP 4-Channel NVR with PoE Switch, 50Mbps, HDD Not Included (Replaces XRN-410S)
XRN-420S | SQ-XRN420S
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
4K NVR (Intel-based), 4CH with 4 PoE/PoE+ ports (PoE Budget 50W), H265,H264, MJPEG, 1 fixed internal SATA HDDs (6TB max), ARB (Automatic Recovery Backup), 50Mbps recording, up to 32Mbps playback, Dual stream recording, WiseStream technology, HDMI/VGA dual display, max. resolution of 8MP recording/display, AI search (Wisenet AI cameras only), QR Code. No HDD.
Main Features
- Up to 4CH, 8MP camera supported
- H.265, H.264, MJPEG codec
- AI Search: Object Attribute (When integrated with AI Camera)
- 50Mbps network camera recording
- Plug and play by 4 PoE (LAN, 10/100), 1 PoE (WAN, 1Gbps)
- Max. 1HDD (Max. 6TB)
- HDMI / VGA local monitor
- ARB supported
- P2P service (QR code connect) support
- No HDD
General Information
Name: Hanwha XRN-420S X-Series 8MP 4-Channel NVR with PoE Switch, 50Mbps, HDD Not Included (Replaces XRN-410S)
Category: Hanwha Vision, Video Surveillance, Recording Devices & Servers, Network Video Recorders (NVRs), ADI Pro Rewards
UPC Code: 8801089177933
Country of Origin: Vietnam. Country of origin is subject to change.
Specifications
ADI Part Number SQ-XRN420S Bandwidth 50 Mbps Brand Name Hanwha Vision Manufacturer Hanwha Group Manufacturer Part Number XRN-420S Product Model XRN-420S Product Name 4 Channel NVR Product Series X Product Type Video Surveillance Station
Effective Camera Resolution 8MP Maximum Frame Rate 120fps Number of Channels 4 Power Consumption 67W Storage Capacity No HDD Video Formats H.264, H.265, MJPEG
HDMI Yes Number of USB Ports 1
Ethernet Yes Remote Management Yes
Depth 8.2" Height 1.9" Width 11.8"
Hard Drive Capacity No HDD
Maximum Resolution 1280 x 720
