VIVOTEK FD9380-H C-Series 5MP Outdoor IR Dome Camera, 2.8mm Fixed Lens, White
VIVOTEK FD9380-H C-Series 5MP Outdoor IR Dome Camera, 2.8mm Fixed Lens, White
VIVOTEK FD9380-H C-Series 5MP Outdoor IR Dome Camera, 2.8mm Fixed Lens, White
FD9380-HF2 | T6-FD9380HF2
Please sign in to view pricing and availability and to add to cart.
Product Overview
VIVOTEK's FD9380-H is a H.265 outdoor dome network camera equipped with a 5-Megapixel sensor, enabling resolution of 2560x1920 at 20 fps. Featuring VIVOTEK SNV and WDR Pro technology, the FD9380-H is capable of capturing high-quality imagery in both high contrast and low light environments. The FD9380-H deploys a 2.8mm/3.6mm lens and is equipped with IR illuminators with a 30-meter effective range for better night visibility. Further, to provide reliable coverage in harsh outdoor environments, the FD9380-H is encased in IP66 and IK10 housing.
By employing VIVOTEK's Smart Stream III technology and H.265 codec support, the FD9380-H is able to reduce bandwidth usage by up to 90% while maintaining supreme image quality. Additionally, the VADP (VIVOTEK Application Development Platform) allows users to customize applications for the ever-expanding number of user scenarios in a diversifying surveillance market.
Main Features
- For remote surveillance needs, this network camera is best suited
- Up to 2560 x 1920 video resolution
- CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
- 2.80 mm maximum focal length with sharp output to help identify and locate the object with added efficiency
- Up to 98.43 ft of night vision
- HD recording format for a lively video quality experience with maximum dependability
- Fixed lens type effectively compensates for changes in the level of light by adjusting the exposure time or using gain
- Wall Mount mount type allows convenient, easy usage with maximum efficiency
- Wired connectivity technology delivers exceptional performance to offer maximum usability
General Information
Specifications
ADI Part Number T6-FD9380HF2 Brand Name VIVOTEK Manufacturer Vivotek, Inc Manufacturer Part Number FD9380-HF2 NDAA Compliant Yes Product Model FD9380-HF2 Product Name FD9380-HF2 Network Camera Product Type Network Camera Weight 1.19 lb
Connectivity Technology Wired Effective Camera Resolution 5MP Lens Type Fixed Maximum Frame Rate 20fps Minimum Focal Length 2.8mm Night Vision Yes Video Formats H.264, H.265, MJPEG
Night Vision Distance 98.43 ft Wide Dynamic Range Yes
Maximum Video Resolution 1600 x 1200
Maximum Operating Temperature 140°F (60°C) Operating Humidity 0.9
Longest Shutter Speed 1/5 Second
Network (RJ-45) Yes
Focal Length 2.8 mm Lens Included Yes Maximum Focal Length 2.8 mm
Remote Management Yes
Color White Depth 3.5" Durability Dustproof, Impact Resistant, Waterproof Form Factor Dome Height 4.6" Width 4.6"
Mount Type Ceiling Mount, Wall Mount
Recording Formats HD
Limited Warranty 2-Year
Impact Protection Rating IK10 Indoor/Outdoor Outdoor Ingress Protection Rating IP66 TAA Compliant Yes
