VIVOTEK IB9388-HT C-Series 5MP Outdoor IR WDR Bullet IP Camera, 2.8-12mm Lens, White

VIVOTEK IB9388-HT C-Series 5MP Outdoor IR WDR Bullet IP Camera, 2.8-12mm Lens, White

VIVOTEK IB9388-HT C-Series 5MP Outdoor IR WDR Bullet IP Camera, 2.8-12mm Lens, White
IB9388-HT | T6-IB9388HT
Please sign in to view pricing and availability and to add to cart.
Product Overview
Key Features
- H.265 Compression Technology
- 20 fps @ 2560x1920 (WDR Pro on)
- 2.8~12 mm, Remote Focus
- SNV (Supreme Night Visibility) for Low Light Conditions
- WDR Pro for Unparalleled Visibility in Extremely Bright and Dark Environments
- Smart Stream III to Optimize Bandwidth Efficiency
- Built-in IR Illuminators, Effective up to 30 Meters
- Trend Micro IoT Security
- Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
- Built-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
Overview
VIVOTEK's IB9388-HT is a H.265 outdoor bullet network camera equipped with a 5-Megapixel sensor, enabling resolution of 2560x1920 at 20 fps. Featuring VIVOTEK SNV and WDR Pro technology, the IB9388-HT is capable of capturing high-quality imagery in both high contrast and low light environments.
The IB9388-HT deploys a remote focus lens for different user scenarios. IR illuminators are equipped with a 30-meter effective range for better night visibility. Further, to provide reliable coverage in harsh outdoor environments, the IB9388-HT is encased in IP66 and IK10 housing.
By employing VIVOTEK's Smart Stream III technology and H.265 codec support, the IB9388-HT is able to reduce bandwidth usage by up to 90%* while maintaining supreme image quality. Additionally, the VADP (VIVOTEK Application Development Platform) allows users to customize applications for the everexpanding number of user scenarios in a diversifying surveillance market.
Main Features
- H.265 Compression Technology
- 20 fps at 2560x1920 (WDR Pro on)
- 2.8~12 mm, Remote Focus
- SNV (Supreme Night Visibility) for Low Light Conditions
- WDR Pro for Unparalleled Visibility in Extremely Bright and Dark Environment
- Smart Stream III to Optimize Bandwidth Efficiency
- Built-in IR Illuminators, Effective up to 30 Meters
- Trend Micro IoT Security
- Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
- Built-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
General Information
Specifications
ADI Part Number T6-IB9388HT Brand Name VIVOTEK Manufacturer Vivotek, Inc Manufacturer Part Number IB9388-HT NDAA Compliant Yes Product Model IB9388-HT Product Name Bullet Network Camera Product Series C Product Type Network Camera Weight 1.63lb
Connectivity Technology Wired Effective Camera Resolution 5MP Lens Type Varifocal Maximum Frame Rate 20fps Minimum Focal Length 2.8mm Night Vision Yes Number of IR LEDs 2 Optical Zoom 4.3x Video Formats H.264, H.265, MJPEG
Night Vision Distance 98.43 ft Wide Dynamic Range Yes
Maximum Video Resolution 1600 x 1200
Maximum Operating Temperature 140°F (60°C)
Network (RJ-45) Yes
Focal Length 12 mm Lens Included Yes Maximum Focal Length 12 mm
Remote Management Yes
Color White Durability Dustproof, Impact Resistant, Waterproof Form Factor Bullet Height 8.4" Width 3.3"
Mount Type Corner Mount, Junction Box Mount, Pole Mount
Recording Formats HD
Limited Warranty 24-Month
Impact Protection Rating IK10 Indoor/Outdoor Outdoor Ingress Protection Rating IP66 Package Contents - Bullet Network Camera
- Quick Installation Guide
- Alignment Sticker
- Screw Pack
- Cable Gland
TAA Compliant Yes
