Tripp Lite N286-01GLX-SLX HP J4859C Compatible SFP Transceiver, 1000Base-LX, DDM, Singlemode LC, 1310nm, 10km
N286-01GLX-SLX|TC-N28601GLX
Tripp Lite N286-01GLX-SLX HP J4859C Compatible SFP Transceiver, 1000Base-LX, DDM, Singlemode LC, 1310nm, 10km
N286-01GLX-SLX|TC-N28601GLX
Eaton Tripp Lite
Tripp Lite N286-01GLX-SLX HP J4859C Compatible SFP Transceiver, 1000Base-LX, DDM, Singlemode LC, 1310nm, 10km
N286-01GLX-SLX | TC-N28601GLX
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The N286-01GLX-SLX HP J4859C Compatible 1000Base-LX LC SFP Transceiver with a duplex LC female connector functions just like the HP J4859C transceiver module and is designed to operate with HP networking equipment. It also meets or exceeds the J4859C's original specifications and complies with MSA (Multi-Source Agreement) standards. This 1000Base-LX transceiver is fully hot-pluggable, so you can install it without shutting down the network or rebooting your device. It supports data transfer rates up to 1Gbps with 1310 nm wavelength signaling. It transmits across six miles (10km) of 9/125 SMF cabling. The N286-01GLX-SLX also supports DDM, so you can monitor optical output power, optical input power, temperature, laser bias current and transceiver supply voltage. It is electrical interface-compliant with SFF-8431 specification.
Main Features
- Hot-pluggable for installation without rebooting or shutting down
- Data transfer rates up to 1 Gbps
- Transmits up to 6 miles (10 km) with 9/125 SMF cabling
- Supports DDM
- Electrical interface-compliant with SFF-8431 specification
- 1310 nm wavelength signaling
General Information
Name: Tripp Lite N286-01GLX-SLX HP J4859C Compatible SFP Transceiver, 1000Base-LX, DDM, Singlemode LC, 1310nm, 10km
Category: Eaton Tripp Lite, Data Comm & Networking, Media Converters & Transceivers, SFP Modules
UPC Code: 037332197436
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number TC-N28601GLX Brand Name Eaton Tripp Lite Manufacturer Tripp Lite Manufacturer Part Number N286-01GLX-SLX Product Model N286-01GLX-SLX Product Name HP N286-01GLX-SLX SFP (mini-GBIC) Module Product Type SFP (mini-GBIC)
Fiber Optic Mode Single-mode Media Type Supported Optical Fiber
Connector Type LC Interfaces/Ports Details 1 x LC Duplex 1000Base-LX Network
Network Technology 1000Base-LX
Ethernet Technology 10 Gigabit Ethernet
Application/Usage Data Networking, Optical Network Depth 2" Form Factor Hot-pluggable Height 0.3" Width 1"
Country of Origin CN Environmental Certification RoHS Environmentally Friendly Yes Package Contents - N286-01GLX-SLX HP J4859C Compatible 1000Base-LX LC SFP Transceiver
- Owner’s manual
