Eaton Tripp Lite N845X-02M-8L-MG Fiber Optic Patch Cable, Multimode MPO/LC, 2M
Eaton Tripp Lite N845X-02M-8L-MG Fiber Optic Patch Cable, Multimode MPO/LC, 2M
Eaton Tripp Lite N845X-02M-8L-MG Fiber Optic Patch Cable, Multimode MPO/LC, 2M
N845X-02M-8L-MG | TC-N845X02M8
Please sign in to view pricing and availability and to add to cart.
Product Overview
40/100 GbE Cable Supports Higher Bandwidths Needed for High-Density Data Networking
As the amount of traffic in data networks grows, so does the need for devices and fiber cables to support higher bandwidths for high-density patching between data center MDFs and IDFs in enterprise installations. This multimode 50/125 OM4 fan-out cable is an ideal choice for 100 Gb Ethernet applications up to 100 meters (328 feet) at 850 nm. It is also backward compatible with 10 Gb and 25 Gb networks, so you can future-proof your current application for an eventual upgrade to 400 Gb.
Switchable LC Connectors Allow Easy Polarity Conversions
The switchable LC/PC duplex ends let you easily switch the fiber polarity without tools or the need to re-terminate the connectors. Use the detachable clip to keep the connectors in place while in use.
Magenta Jacket Helps Avoid Misidentification That Can Cause Costly Downtime
The OM4-rated cable has a magenta jacket to identify it as multimode in a crowded patch panel or switch and prevent it from becoming accidentally disconnected. The round low-smoke zero-halogen (LSZH) jacket limits the amount of toxic smoke emitted in case of combustion, making it suitable for poorly ventilated areas. The connectors' slim boots allow easy one-handed installation and removal of the cable.
Main Features
- Supports 40/100 GbE for high-density networking
- Backward compatible with 10/25 Gb networks
- Switchable LC Connectors for easy polarity conversion
- Magenta jacket for easy identification
- LSZH Jacket reduces toxic smoke emissions
- Slim boots for easy installation and removal
General Information
Specifications
ADI Part Number TC-N845X02M8 Brand Name Eaton Tripp Lite Manufacturer Eaton Manufacturer Part Number N845X02M8LMG Packaged Quantity 1 Product Model N845X-02M-8L-MG Product Name N845X-02M-8L-MG Fiber Optic Duplex Trunk Network Cable Product Type Network Cable
Cable Type Fiber Optic Connector on First End 1 x MTP/MPO Female Network, 12- Connector on Second End LC Male Network Core/Cladding Diameter 50/125 µm Device Supported Network Device, Patch Panel, Switch Fiber Category OM4 Fiber Count 8 Fiber Optic Mode Multimode Jacket Type LSZH, OFNR Solid or Stranded Stranded
Data Transfer Rate 100 Gbit/s
Cable Length 6.56' Color Magenta Jacket Material LSZH
Limited Warranty Lifetime
Compatibility For devices and fiber cables Country of Origin CN Environmental Certification EcoLogo Environmentally Friendly Yes Features Bendable, Polished Connector (PC), Push-Pull Tab, Stranded Package Contents - N845X-02M-8L-MG 40/100G Multimode 50/125 OM4 Fiber Optic Cable, Magenta, 2 m (6.6 ft.)
